Free App Mini Size Easy Hidding GPS Tracker Car GPS With Alarm Mic

Free App Mini Size Easy Hidding Factory Price GPS Tracker/Car GPS With Alarm And Mic


Main components: (V1.0)


GPS functions:

protocol: GT06 1)support ACC ignition checking ,
G-sensor : BS250E 2)support Relay for cutting off power/fuel
input power: 9-100V 3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H 4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm, GPS module: Ublox 6) platform /APP supported

Multi-Mode Positioning: BD GPS LBS


Device status indicators

4.1 Connect DC 9-100V power supply and the red LED will light continuously.
The red LED is the power signal,
it is always on when the external DC is connected.


4.2 The blue LED is the GSM signal indicator.
It is always on when there is no GSM;

it flashes when GSM is normal;

it flashes quickly when transmitting data.


4.3 The yellow LED is the GPS signal indicator:
it is always on when there is no positioning;
it flashes after positioning.

Free App Mini Size Easy Hidding Factory Price GPS Tracker/Car GPS With Alarm And Mic

GPS Tracker Parameters:

GPS Tracker Applications And Where you install it.

Free App Mini Size Easy Hidding Factory Price GPS Tracker/Car GPS With Alarm And Mic
GPS Tracker Main Functions:

1. Real-Time Positioning:

TK004 GPS Tracker Device will get the real-time position message and upload all status to the server system.

And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. speed

GPS Time, direction, and so on.

Installation for the Car/Motorcycle/E-bike

The GPS tracker must be installed under professional personnel.

Note:

1) Please install the device in the hidden place as follows:

Under Front windshield；

In the front instrument panel；

Under back windshield；

2) Avoid being placed with signal radiators like reverse sensor ；

3) The device has a GSM antenna and GPS antenna inside. Please ensure the receiving side of the device is face up and without a metal cover.

Note: The metal cover will lessen the receiving of GPS signals.

Similar GPS Tracker TK003

2. Vibration alarm:

After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.

3.  Power-off alarm:

If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.

4.  Remote Car Lock

If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.

5.  SOS Alarm

Users can press the SOS button on GPS Tracker in emergency situations. GPS Tracker will send an alarm message to manage the system and
Call police simultaneously.

Terminal connection:

male switch, Female switch
Red(positive) Black (Negative)

1. red wire connect positive(+),black wire connect negative(-)
2. power input connector to power positive and negative connectors( make sure connect the right connector)


GPS Tracking Device TK003 Vehicle Tracking Mini Gps Tracking

1,Preparation Before Use

1. Prepare a nano sim card which compatible with 2G GSM network,

if a new SIM card, need 24 hours to activate properly; also need to set off the PIN code of the sim card

2. Open GPRS and Caller ID Display service of the sim card

3. Scan QR code on the first page to download 365GPS APP

2,Power on

Insert the nano sim card into the tracker's sim card slot ( there is a missing angle alignment for a sim card and the slot ), power button is the black button next to the sim card slot.

Power On: long press for 3seconds

SOS: long press for 3seconds in power on mode

Power off: long press for 10seconds (with sim card)

Power off: long press for 3seconds (without sim card)

 Other product

CA-P


How to ship goods?


FAQ:

Q: Are you a manufacturer?
A: Yes, we are a manufacturer for GPS Tracker in China with 10years of experience
Q: What is the applicable range of this product?
A: We on intelligent vehicle terminal for logistics vehicles, private cars, taxis, motorcycle, e-bike, motorbike, etc
Q: Can your products pass CE/ROHS certificate?
A: Yes, our products meet the industrial standards, like CE/ROHS/CCC/FCC/MSDS
Q: Payment method?
A:1.We accept T/T bank, Weston Union, and Paypal.
2.100% payment before shipping
Q: What is your warranty for goods?

A:1.All goods have a warranty for 1 year
2.If there is any product is defective, please notify us within 7 days of delivery


How to use this GPS tracker?

1. Input SIM Card inside the GPS Tracker product.

2. Connecting GPS Tracker with power supply.

3.  Put a GPS Tracker device near a window or some open area waiting for signal ready.

4.  When all indicators lighted and flashed normally means GPS Tracker works. now send SMS command to
communication network, you will receive a GPS Tracker status report by SMS.
