ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking

I'm Online Chat Now
Certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking

ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking
ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking

Large Image :  ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking Get Best Price

Product Details:
Place of Origin: China
Brand Name: Blank
Certification: CE/ROHS/FCC/SGS ISO9000
Model Number: BW12
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 10,000pcs per month
Detailed Product Description
Use: Automotive Unit Weight: 40g
Working Voltage: 9-50V Fuction: Real Time Positiong/remote Monitoring
Size: 6.8(L)x3.8(W)x1.1(H)cm Battery: Internal Battery
Bands: GSM Worldwide 4 Bands Application: Webplatform/App
High Light:

ACC Detection Mini Vehicle Gps Tracker

,

10m Mini Vehicle Gps Tracker

,

ACC Detection Fuel Sensor GPS Tracker

Mini Vehicle Gps Tracker For Car Motorcycles ACC Detection Fuel Sensor Tracking

Function
◇ GPS satellite & LBS base station dual model positioning
◇ Vibration alarm (sensitivity is adjustable from 1 to 5 grade)
◇ GEO-fence
◇ Low current consumption sleep mode
◇ ACC detection(Digit input1: 9-50V)
◇ AC detection(Digit input2: 9-50V)
◇ ADC detection(Analog input: 0-100V): support fuel sensor, temperature sensor
◇ +5V output for sensor power supply
◇ Remote control cut-off/on engine (petrol / electricity)
◇ Power cut off alarm
◇ SOS Alarm
◇ Voice monitoring
◇ 128M data storage while no GSM.





Parameters

Items Specification
Type BW12
Unit Size 68(L)*38(W)*11(H)mm
Color Black
SIM Card Slot One
Voltage input range 9–36V
GPS positioning precision 10m(2DRMS)
Weight 0.04kg
Humidity 20% - 80% RH
Working Temperature -20~70°C
Geo-fence Geo -fence alarm support
Language Support 50+ Languages on platform
GSM+GPRS+GPS GPS Location
History Trace History Report
GPS positioning time Cold start -38S (OPEN SKY)
Hot start -2S (OPEN SKY)
GPRS CLASS12,TCP/IP
GSM Frequency 850/900/1800/1900 MHz



ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking 0



ACC alarm Function:
Send following sms to set the ACC alarm. And the tracker will send the alarm via sms and call to admin while acc alarm occurred .
#6666#ACCAM#0#
(0=disable ACC alarm; 1= ACC ON alarm; 2= ACC OFF alarm; 3= ACC ON and OFF alarm)


Digit input2 alarm Function:
Send following sms to set the input2 alarm. And the tracker will send the alarm via sms and call to admin while acc alarm oc curred .
#6666#input2AM#0#
(0=disable input2 alarm; 1= input2 ON alarm; 2= input2 OFF alarm; 3= input2 ON and OFF alarm)


Analog input Function: (Calibration of fuel sensor )
Tracker has ADC detection(A nalog input) function, the input voltage range is from 0.0V to 100.0V, you can connect car original voltage type fuel sensor or add on voltage type fuel sensor to this port D ue to the different height of fuel tank and fuel sensor specifications, tracker need s to be set appropriate zero rang value and f ull range value to detect the precise fuel percentage.


Zero calibration: Send “ #6666# “ to tracker when the fuel tank is empty then tracker will adjust zero range automatically and reply “Getting oilzero ok! value= V you can also send sms co mmand #6666#oilzero#0.1# to define the different voltage value when fuel tank is empty and it will Setting oilzero ok! value= V


Full calibration: Send “ #6666# “ to tracker when the fuel tank is full then tracker will adjust full range automatically and reply “Getting oilfull ok! value= V you can also send sms command #6666#oilfull#5.1# to define the different voltage value when fuel tank is full and it will Setting oil full ok!  value= V "
#6666#checkoil# is the command for checking percentage , current oilzero oil full values.
If full calibration is set as 0.0V,then tracker does not give percentage value but ADC voltage value in gprs package.

ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking 1

Mini Vehicle Gps Tracker For Car Motorcycles ACC Detection Fuel Sensor Tracking

FAQ



Q1. What is your terms of payment?
Normally the payment term is 100% before shipment. For above 10000$, the payment term can be T/T 30% as deposit, and 70% before delivery.

Q2. What is your sample policy?
We can supply the samples if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q3. How about your delivery time?
The specific delivery time is depended on the items and the quantity of your order.

Q4. Can you providing GPS tracking system and APP?
Yes, we have our GPS tracking software/system and APP. We also provide our protocol for integrating to your system.

Q5: Does the GPS tracker need a SIM card?
1. It depends on the models. Most of our GPS tracking devices need the SIM card, please check the network details from the product description before ordering.
2. Normally 4G device can compatible with 3G and 2G network, so a 4G SIM card is needed. 2G/3G SIM card can’t work on 4G device. NB-IOT devices need NB-IOT network, please check with your operator to confirm if your area has been covered with stable NB-IOT network.
3. We are also able to do customization on e-SIM solution. Just feel free to contact us if needed.

ACC Detection Mini Vehicle GPS Tracker For Car Motorcycles Fuel Sensor Tracking 2
