Mini Small Wired Smart Car GPS Tracker For Vehicle With Accurate Positioning
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Mini, Wired | Positioning Mode: | GSM, GPS, GPRS, LBS, |
|---|---|---|---|
| Warranty: | 1 Year | Operating Voltage: | DC9-95V |
| Dormant Current: | 5mA - 15mA@12V | GPS Accuracy: | 5-10m |
| Battery Capacity: | Rechargeable 3.7V 140mAh | Chip: | MT6261 |
| High Light: | Wired Smart Car GPS Tracker,Accurate Positioning Smart Car GPS Tracker,Accurate Positioning Wired Car GPS Tracker |
||
Mini Small Wired Smart Car GPS Tracker For Vehicle With Accurate Positioning
Product Description
| Model | TK003 |
| GSM Specifications | |
| GSM channel | 850/900/1800/1900MHz |
| GPRS class | Class 12,TCP/IP |
| Communication protocol mode | TCP |
| GPS Specifications | |
| frequency | L1,1575.42Mhz C/A code |
| Number of channels | 66 |
| Positioning accuracy | <10 meters |
| Working Parameters | |
| Operating Voltage | DC9V-95V |
| Working current | 25ma |
| battery | 140mAH |
| Continuous working time | 2h |
| Continuous stationary battery life | 4h |
| Dimensions | L76mm *W26mm*H19mm |
| weight | 30g |
| Waterproof and dustproof level | IP65 |
| Features | |
|
|
Remotely Cut Off Fuel
When the car is stolen, you can control your car remotely on your mobile phone by sending the SMS command "RELAY,1#" to cut off the engine, the car will stop moving until you receive the SMS command "RELAY,0#" to prevent your car from being stolen in the car park, (the car will stop within 10-20 seconds)
Alarm SMS
The device has a variety of alarm functions, including power failure alarm, anti-theft alarm, speeding alarm, ACC alarm and other alarm functions.
When the alarm is triggered, the device will send an alarm SMS to the phone number you set, and the platform will also receive the alarm message from the device.
Real-time tracking
Users can view the real-time route of the vehicle through the platform and keep track of the vehicle information.
Track playback
Users can use the platform to check the distance travelled by the device in the past time, generating detailed travel records, speed reports and trip reports.
Monitoring interface
User can view all device information in the monitoring interface, receive real-time alarm messages from all devices, set fences for devices and track the travel routes of multiple devices at the same time.
Reporting Interface
The platform provides a variety of reports to analyse and summarise information about all devices, and users can query and export data from the reports.
ACC detection
Mileage statistics, ignition detection, vehicle voltage detection, Real-time detection of vehicle usage status to avoid private use of external wiring.
Mini Small Wired Smart Car GPS Tracker For Vehicle With Accurate Positioning
Our Service
1. We support one year platform free, during the period, you can use our platform without any restriction. If expired, please contact after-sales person for renew.
2. The device has one year free replacement. Faulty device must be reported and returned within the warranty period, keep original package if possible. Device expired warranty is not acceptable.
3. WanWayTech online technical support team will service you. In the box, you can find our after-sales service card, if any question, please don't hesitate to contact us. Your satisfaction is our inexhaustible motive force.
FAQ
Q1. Do this gps tracker need a sim card?
A: Yes, this device needs a sim card which support 2g gsm network.
Q2: How many data traffic will it use monthly?
A: Usually 50mb
data traffic will be need. For saving data traffic, you can set positioning time interval for device.
data traffic will be need. For saving data traffic, you can set positioning time interval for device.
Q3: Why gps tracker show offline on the platform?
A: When you meet this situation, please check your sim card if it works normal. Try to send sms command "status#", show the reply message to our after-sales team, they will help.
Q4: How long will i get the package after payment?
A: This depends on logistics system. In normal condition, the package will arrive at your address in 30 days.
