Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine

Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine
Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine

Large Image :  Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine Get Best Price

Product Details:
Place of Origin: China
Brand Name: YTWL
Certification: CE/ROHS/FCC/SGS ISO9000
Model Number: TK004
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 10,000pcs per month
Detailed Product Description
Type: Mini, Wire Positioning Mode: GPS, LBS, Beidou,Real-Time Positioning
Battery Life (Hour): <2H Battery: Built-in 140mAh
Network: 2G GSM Quad Bands Material: ABS Plastic
SIM Card: Micro Sim Card Warranty: 1 Year
High Light:

Car GPS Tracker 140mAh

,

ABS Plastic Car GPS Tracker

,

Mini GPS Tracker ACC Ignition

ACC Ignition SOS Call Audio Monitoring Car Gps Tracker With Relay Stop Engine

Function:
1. Build-in GPS Vehicles locator
2. Support 4-frequency GSM 850/900/1800/1900 MHz which can Work worldwide
3. Support track the real time address by google link
4. Built in battery 140 mAh,when the engine starts will charge,no worry outage
5. Support GEO Fence Alarm
6. Main Power Off Alarm (with built battery only)
7. Support Vibration Alarm
8. Support Overspeed Alarm
9. Support SOS emergency call
10. Support Microphon voice listening



Specification
Communication System
WCDMA/GSM
Frequency
WCDMA 850/900/1900/2100MHz
Networks
Class 3 (24dBm +1/-3dB) for UMTS bands
Networks
GSM 850/900/1800/1900MHz
GPS Chip
MTK high sensitivity GPS chip
Location Accuracy
<10 meters
GPS starting time
Hot start:≤2sec(open sky)
Cold start:≤35sec(open sky)
Voice Monitor Scope
≤ 5M
Antenna
Built-in GPS ceramic antenna; GSM quad-ban antenna
LED Indicator
GPS(blue), GSM(green), Power(red)
Operating Voltage
9-36VDC
Operating Temperature
-20℃-70℃
Operating Humidity
5%~95%,non-dense
Built-in Battery
140mAh/3.7 lithium polymer battery
Standby
2 hours
Data Transmit
TCP, SMS
Geo-fence Alarm
support
Over speed Alarm
support
Movement Detection
support
SOS alarm
support
Voice listening
support



Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine 0



Over Speed Alarm
When the car is moving over a limited speed in average in a limited time period, the device will send over speed alarm SMS to user. In this way, we can pay attention to the use of the car and avoid the unexpected accident.



Voice Monitoring
Any soS number calls our GT06E and keep ringing for more than 10s, the device will enter voice monitoring status, we can monitor the sound around the device. The device will not make any noise during the monitoring process.



Door Detection (Optional)
The device is bale to detec door status. It uploads car status to platform and APP timely.
When car door's status is negative triggering,there is no need to set. Instead, if car door status is positive triggering, the triggering way has to be modified.

Audio Monitoring Car GPS Tracker ACC Ignition SOS Call With Relay Stop Engine 1



ACC Ignition SOS Call Audio Monitoring Car Gps Tracker With Relay Stop Engine



Our Service
1. We support one year platform free, during the period, you can use our platform without any restriction. If expired, please contact after-sales person for renew.
2. The device has one year free replacement. Faulty device must be reported and returned within the warranty period, keep original package if possible. Device expired warranty is not acceptable.
3. YTWL online technical support team will service you. In the box, you can find our after-sales service card, if any question, please don't hesitate to contact us. Your satisfaction is our inexhaustible motive force.



FAQ
Q1. Do this gps tracker need a sim card?
A: Yes, this device needs a sim card which support 2g gsm network.
Q2: How many data traffic will it use monthly?
A: Usually 30mb data traffic will be need. For saving data traffic, you can set positioning time interval for device.
Q3: Why gps tracker show offline on the platform?
A: When you meet this situation, please check your sim card if it works normal. Try to send sms command "status#", show the reply message to our after-sales team, they will help.
Q4: How long will i get the package after payment?
A: This depends on logistics system. In normal condition, the package will arrive at your address in 30 days.
