Fleet Management Online Vehicle GPS Tracker ACC Detection Fuel Sensor Monitoring

Fleet Management Online Car GPS Tracker ACC detection fuel sensor monitoring voice listening

Overview of the characteristics:

1. GPS position.

2. GSM 850/900/1800/1900MHZ.

3. With Shock sensor.

4. Power-Cut alarm.

5. Auto set APN.

6. Voltage 9-36V.

7. SOS alarm.

8. Voice Surveillance.

9. ACC detect.

10. Support fuel sensor

11. 5V OUTPUT

12. Digit input2

Specification

1).GSM:850/900/1800/1900MHZ

2).GPRS: Class12, TCP/IP

3).Working Voltage:9-36V DC

4).Working current:22mA (12VDC)

5).Working current:12mA (24VDC)

6).GPS locating time:

Cold start:38s(Open sky)

Warm start:32s

Hot start:2s(Open sky)

7).GPS Precision:10m(2D RM)

8).Working temperature:-20 Celsius~+70 Celsius

9).Working humidity:20%~80%RH

Parameters

Fleet Management Online Car GPS Tracker ACC detection fuel sensor monitoring voice listening

FAQ

Q: Why the tracker can't be switched on?

A: 1. Check if wiring is correct or not.

2. Charge the tracker.

Q: No response to SMS command

A: 1. Wrong password. Please check your password.

2. No GSM mobile signal or weak GSM network. Try later.

3. Out of SIM credit. Please pop up.

4. SIM is damaged. Change a sim card.

5. SIM card is without sending function. Change a SIM or enable SMS sending function and caller identification function.

6. SIM card isn't installed properly.

Q: Is there a monthly charge for it to communicate with me. Does it require a cellulare service provider or something else?

A: Two communication ways: SMS ( just like one mobile phone to another) and GPRS ( monitor/manage the tracker on our tracking platform) . These two ways are both charged by your local telecom carrier, we don't charge for the SMS or GPRS fee.

Note:

1. you can just choose one or both two of the two way communications to get the real time location info and so on from the tracker : SMS or GPRS or both )

2. No matter via SMS or GPRS communication, there is one simcard(the one has gprs function and caller identification function, you'd better buy from the local telecom carrier) needed to be inserted in the tracker. NO data plan required by us.
