Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System

I'm Online Chat Now
Certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System

Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System
Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System

Large Image :  Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System Get Best Price

Product Details:
Place of Origin: China
Brand Name: YTWL
Certification: CE ISO RoSH
Model Number: CA100F
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 10,000pcs per month
Detailed Product Description
Warranty: 2 Years Net Weight: 280g
Speed Limit Scope: 40-120KM/H Working Voltage: DC 9-36V
Working Current: < 40mA Model Number: CA100F Or OEM
Communication Module: GSM Working Power: 5W
High Light:

Fleet Management Car Speed Limiter

,

GPRS Quad Band Gps Tracker

,

Car Speed Limiter BT360I

Ethiopia Standard GPS Speed Limiter GPS Tracking Function Fleet Management System

Technical Parameter:

Content Specs.
Network GSM/GPRS/GPS
Band 850/900/1800/1900MHz
GPS chip U-blox
GSM/GPRS Module SIM800C
Bluetooth Module BT360I
CPU STM32F105RBT6
Power IC TD1509-ADJ
Anti-jamming Strengthened Anti-jamming
GPS sensitivity -159dBm
GPS accuracy 5 m
Work Voltage DC 9V-36V
Battery Rechargeable 3.7V / 1000mAh Li-ion battery (Customizable)
Standby work current < 40mA
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +70°C
Humidity 5%--95% non-condensing
Speed Limit Scope 40-120KM/H
Frequency 850/900/1800/1900Mhz
Working Power 5w
Time To First Fix Reacquisition 0.1s
Cold status 45s
Warm status 35s
Hot status 1s



Product description

Extension functions
1) Mainly used in Kenya to control vehicle speed and further expand the market for auto speed limiters in Ethiopia.
2) Vehicle speed pulse detection; it is a speed limiter and also a GPS tracker, surpassing the traditional GPS tracker.
3) One channel high input detection, one channel low input detection;
4) One channel power-off control output, one channel oil-off control output;
5) Three channels of analog input. One is used for fuel consumption data detection, another is used for the ordinary analog voltage detection, the third one is for standby;
6) One channel RS232 defining interface;
7) One channel RS232/RS458 compatible interface;
8) The (G-SENSOR) acceleration sensor interface reserved, can open for some customer need.



Fixed Highest Speed Limiting
Can set only one or two highest driving speed value for the vehicle. Such as: According to the government regulations, some vehicle should not driving over 100Km/h(or any other appointed speed), the product can control the vehicle keep driving within 100Km/h(or any other appointed speed)



Differentiate Road Type Intelligent Speed Limiting
Limit the highest vehicle speed according to different road type.
Such as: on high-speed road, speed limit within 120 100Km/h; for fast road, speed limit within 100 Km/h, State Road 60Km/h, county road limit 50Km/h, this product according to road speed limit.

Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System 0





Ethiopia Standard GPS Speed Limiter With GPS Tracker Functions GPS Fleet Management System

FAQ
Q: How to monitor the GPS Tracker?
A: User can login the web gps tracking software and Phone IOS/Android Tracking APP to monitor their vehicle or pets or kids respectively at real time.

Q: Can I have admin account at the gps tracking system and any monthly cost?
A: We shall offer you admin account so you can create subaccount. No monthly or yearly subscription charge for long term business.

Q: How do you support me and what is the warranty?
A: We offer real time support by Phone, Email and Whatsapp. 24 months warranty available.

Q: Can the GPS tracking device work in my country?
A: Almost all the rest countries still support 2G internet and use 2G GPS tracking system.

Q: What is minimum order quantity?
A: We advise clients to take at least 2 samples for testing purpose.
