Mini 4G Gps Tracking Device Realtime Position Gps Tracker Cut Off Fuel Used For Vehicle Tracking
|
Product Details:
|
Detailed Product Description
| Placement: | Windshield, Instument Panel | Function: | Remote Cut Off |
|---|---|---|---|
| Connection: | 3G/4G Sim Card, 2G Sim Card | Certification: | CE ISO |
| Use: | Automotive | Warranty: | 2 Years |
| Place Of Origin:: | Shenzhen China | Chip: | MT6261 |
| High Light: | FCC 4G OBD GPS trakcer,LBS Locating Diagnostic Code Reader,ACC Input Detection GPS Tracker |
||
Mini 4G Gps Tracking Device Realtime Position Gps Tracker Cut Off Fuel Used For Vehicle Tracking
Improve the performance of your fleet business today with the feature rich and lightning fast C003-01-4G. The C003-01-4G is a powerful and easy to install 4G GPS tracker that gives you actionable telematics insights. In addition to standard functions such as GPS location and geo-fence alerts,
Mini 4G Gps Tracking Device Realtime Position Gps Tracker Cut Off Fuel Used For Vehicle Tracking
Features:
●LTE & WCDMA & GSM
Allow the device to receive and transmit data in the 4G, 3G & GPRS network areas
Allow the device to receive and transmit data in the 4G, 3G & GPRS network areas
●ACC detection for ignition status
Be aware of the ignition status whenever you need
●Remote cut-off (petrol/power)
Compel the vehicle to stop by breaking off the fuel connection
●Multiple alerts
●Multiple alerts
Instant alert for vibration, over-speed, Geo-fence
Mini 4G Gps Tracking Device Realtime Position Gps Tracker Cut Off Fuel Used For Vehicle Tracking
Specifications:
|
GSM Specification
|
|
|
Frequency
|
GSM: 850/900/1800/1900 MHz
|
|
WCDMA: 850/900/1900/2100MHz (B1/B2/B5/B8)
|
|
|
LTE: B1/B2/B3/B4/B5/B7/B8
|
|
|
GPRS
|
Class 12, TCP/IP
|
|
Memory
|
32M+32M
|
|
Phase error
|
RMSPE<5,PPE<20
|
|
Max output
|
GSM850/GSM900:33±3dBm
|
| GSM1800/GSM1900:30±3dBm | |
| WCDMA:24dBm LTE:21dBm | |
|
Max frequency error
|
±0.1ppm
|
|
GPS Specification
|
|
|
GPS chipset
|
U-blox
|
|
Frequency
|
GPS L1, 1575.42MHz
|
|
Location accuracy
|
<10 meters
|
|
Tracking sensitivity
|
-162dBm
|
|
Acquisition sensitivity
|
-149dBm
|
|
TTFF (open sky)
|
Avg. hot start ≤2sec Avg. cold start ≤38sec
|
|
Others
|
|
|
Battery
|
200mAh
|
|
Working voltage/current
|
22mA(12VDC);12mA(24VDC)
|
|
Operating temperature
|
-20℃～ 70℃
|
|
Dimension
|
90(L)*40(W)*15(H)mm
|
|
Weight
|
50g
|
Mini 4G Gps Tracking Device Realtime Position Gps Tracker Cut Off Fuel Used For Vehicle Tracking
FAQ
1. Can GPS Trackers work without SIM card ?
Of course not. Only Trackers and Tracking Software have same GPRS protocols can work together.
2. Can any Trackers work With one same Tracking Software?
Of course not. Only Trackers and Tracking Software have same GPRS protocols can work together.
3. Can I add my GPS Trackers made In other factories to your GPS Tracking Software?
Yes. you can add but it will not work With our Software until we add your Tracker protocol to our Software but it is a hard work and takes much Time. We need to analysis it and get it working if all protocol are complete and workable.
4. I found you have many Trackers and Tracking Software, why don't you make all Trackers working With only one Software?
Some Trackers made In our factory and some are not. it will take several years to make all GPS Trackers working With one Tracking Software. From many years export, we found it not worthy to do it. So please answer me above questions so that we can recommend a right solution For you.
5. Can i use your GPS Tracker In our GPS Tracking Platform?
Yes you can but you need to analysis our Tracker's GPRS protocol and change your Software codes so that they can match.
6. Are The models I bought can be tracked via Web?
Yes. all can Track via Web. but they are coming With different Web.
