Product Details:
Payment & Shipping Terms:
|
Function: | Real Time Tracking | Place Of Origin: | Shenzhen China |
---|---|---|---|
Dimension: | 90mm*40mm*15mm | Input Voltage: | 9-80V |
Positioning Accuracy: | 5m | Antenna: | Built-in GPS Antenna: 18*18*4 Mm |
Weight: | 50g | Warranty: | 2 Years |
High Light: | FCC 4G OBD GPS trakcer,LBS Locating Diagnostic Code Reader,ACC Input Detection GPS Tracker |
Real-time position Locator Remote Monitor Cut-off Power/Fuel 4G Auto Car GPS Tracker
Description
Dimension | 90(L)*40(W)*15(H)mm |
Weight | 50g |
Input Voltage | 9-80V |
Battery | 200mAh |
4G Frequency bands | FDD-LTE 800/850/900/1800/2100/2600MHz |
GPS Chip | GPS Chip |
GPS Sensitivity | -162dBm |
Positioning Accuracy | 5-10m |
Hot start | 1s on average |
Warm start | 32s on average |
Cold start | 38s on average |
Working temperature | -20°C to 60°C |
Humidity | 20%~80% non-concretion |
Antenna | Internal 4G & GPS antennas |
Sensor | Vivration sensor |
LED indicator | Power/GSM/GPS |
SIM Card interface | Standard SIM Card |
Detail
Function: | Real Time Tracking |
Dimension: | 90mm*40mm*15mm |
Positioning Accuracy: | 5m |
Weight: | 50g |
Place Of Origin: | Shenzhen China |
Input Voltage: | 9-80V |
Antenna: | Built-in GPS Antenna: 18*18*4 Mm |
Warranty: | 2 Years |
Real-time position Locator Remote Monitor Cut-off Power/Fuel 4G Auto Car GPS Tracker
Features
4G FDD LTE network support (also support 3G/2G network)
Real-time position acquiring
Vehicle trip history and mileage data on web tracking platform
SOS alarm button and real time reporting (optional)
Geo-Fence alarm and reporting
Vehicle Vibration alarm
Over-Speed alarm and reporting
Applications
Vehicle/truck tracking
Asset security
Fleet Management
Advantages
4G LTE chip solutions
Easy installation
U-BLOX GPS chipset
Unique design & White Label
Protocol is open and compatible other third party platform
IOS & Android support
CE Certificate
OEM
Real-time position Locator Remote Monitor Cut-off Power/Fuel 4G Auto Car GPS Tracker
C003-01-4G model is a small size. Easy install to any vehicle. It can be used locate, track and monitor the vehicle via SMS, PC Computer or Mobile APP. It is commonly used to track and locate individual vehicles, the user also can real time tracking and check the historical route travelled.
C003-01-4G is a wide-voltage vehicle-mounted positioning terminal, the voltage supports 9-100V, the wiring is simple, and the positioning error is about 10 meters (Beidou/GPS signal).
It can be used for electric vehicles, automobiles, motorcycles, etc.
Specification size: 90mm*40mm*15mm
Installation method: fixed installation, Velcro installation
Real-time position Locator Remote Monitor Cut-off Power/Fuel 4G Auto Car GPS Tracker
FAQ:
Q:How can I get more information about your product?
A:You can send us an email or ask our online representatives and we can send you the latest catalog and price list.
Q: Are your APP and platform free to use?
A: Yes, both of them are free to use for lifetime.
Q: As you are the direct manufacturer, can I order one or two samples from you?
A: Yes, we also support sample orders.
Q. What is your terms of payment?
A: T/T or western Union or paypal
