4G LBS Overspeed Alarm GPS Vehicle Tracker 200mAH Built In Antenna
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Function: | Real Time Tracking | Connection: | 3G/4G Sim Card, 2G Sim Card |
|---|---|---|---|
| Certification: | CE ISO | Use: | Automotive |
| Product Name:: | 4g Car Gps Tracker | GSM Frequency: | 850/900/1800/1900/Quad Band |
| Feature: | Real Time Tracking | Working Voltage: | DC9-100V |
| High Light: | Overspeed Alarm GPS Vehicle Tracker,LBS GPS Vehicle Tracker,200mAH Vehicle Gps Tracking Device |
||
Free Web APP 4G GPS Tracker Vehicle Tracker Cut Off Oil Power Realtime Tracking 4G GPS Tracker
Product features:
Accurate positioning, accuracy up to 5 meters.
GPS+ beidou +LBS three-mode positioning.
Industrial design, working voltage 9V - 100V.
Functions:
ACC detection
remote power off
DC detection
power off alarm
overspeed alarm
electronic fence
remote monitor
Free Web APP 4G GPS Tracker Vehicle Tracker Cut Off Oil Power Realtime Tracking 4G GPS Tracker
Device Parameter
| Electric Speicifications |
| Power supply mode: Battery power supply |
| Working voltage range: DC 9V - 100V |
| Working current: 12mA (24vDC) |
| Built-in battery capacity: 200mAH |
| Environmental Features |
| Working temperature range -20℃ - 70℃ |
| Storage temperature range, low - 30 ℃ -80 ℃ |
| Working humidity range - 20%-80%RH |
| Communication frequency band | |
| LTE | FDD-LTE :B1/B3 |
| TDD-LTE :B38/ B39/ B40/ B41 | |
| 3G | WCDMA:B1 |
| TD-SCDMA:B34/B39 | |
| EVDO/CDMA2000 1x :BC0 | |
| GSM/EDGE | B3/B8 |
| Communication antenna - built-in antenna | |
| GPS/LBS Positioning Characteristics |
| Cold start time - average 34 seconds |
| Hot start time - average 2 second |
| Sensitivity (tracking) -162DBM |
| Positioning antenna - built-in antenna |
Free Web APP 4G GPS Tracker Vehicle Tracker Cut Off Oil Power Realtime Tracking 4G GPS Tracker
Description
| Material | Plastic |
| Positioning accuracy | 5-10m |
| GPS module | MT6261 |
| Frequency Band | GSM:850MHz,900MHz,1800MHz,1900MHz |
| 4G:FDD-LTE 800/850/900/1800/2100/2600MHz | |
| GPRS: Class12, TCP/IP | |
| GPS Sensitivity | -159dBm |
| GPS module | MTK6261 |
| Platform | SMS + APP + computer |
| Working Voltage | 9-100V DC |
| Backup Battery: | Built-in battery 200mAh |
| GPS positioning time | 25s |
| Working temperature | -20℃～+70℃ |
| Storage temperature | -40℃～+85℃ |
| Product size | 90(L)×40(W)×15(H)mm |
| Special Functions | Vibration alarm, power failure alarm, SOS alarm, movement alarm, fence alarm, overspeed alarm |
Free Web APP 4G GPS Tracker Vehicle Tracker Cut Off Oil Power Realtime Tracking 4G GPS Tracker
Main components
GPS Functions
protocol: GT06 1)support ACC ignition checking ,
G-sensor : BS250E 2)support Relay for cutting off power/fuel
input power: 9-100V 3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H 4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm,
GPS module: Ublox 6)platform /APP supported
Real Time Tracking
More precise positioning,wider coerage,
More accurate location
Cut and resume oil remotely
Cut off vehichle power or fule with relay
so as to stop vehicle in case of theft
History Route
User can playback vehicle past location details
Geo-fence
when vehicle move in or out preset geo-fence,there is instant alarm.
Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;
Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;
Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.
Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;
Q5: How about your platform cost?
Re: Free for lifetime;
