Placement: | Portbale | Function: | ACC Ignition Checking |
---|---|---|---|
Connection: | 3G/4G Sim Card, 2G Sim Card | Certification: | CE ISO |
Net Work: | GSM/GPRS | Accurancy: | 5M |
Battery: | 200mAH | Net Weight: | 50g |
High Light: | GSM Vehicle Camera GPS Tracker,4G LTE Connectivity GPS Tracker |
Portable Mini GPS Tracker Over Speed Alarm GPS Tracker 2G 3G 4G G-sensor Car Vehicle GPS
Dvice parameter
Electronic Character: | |
Power Supply | built-in battery |
Work Voltage | DC9-100V |
Work Current | ≈22mA (12vDC) |
Work Current | ≈12mA (24vDC) |
Battery Capacity | 200mah |
Environment Character: | |
Work Temp: | -20℃~+70℃ |
Storage Temp: | -30℃~+80℃ |
Work Humidity: | 20%~80%RH |
Communication Character | |
Module Brand/Chip Module | MT6261 |
Band: | B1/B3/B8B34/B38/B390/B40/B41/BC0 |
SIM Card: | Standard SIM card |
Aerial: | Internal |
GPS/BD Positioning Character: | |
Cold start | 38s(Open sky) |
Warm start | 32s(Open sky) |
Hot start | 2s(Open sky) |
Shape | |
Dimension | 90mm*40mm*15mm |
Weight | 50g |
Portable Mini GPS Tracker Over Speed Alarm GPS Tracker 2G 3G 4G G-sensor Car Vehicle GPS
Description
Item | 4G Vehicle Gps Tracker |
Usage | Real-time positioning |
Feature | GPS+BDS+LBS |
realtime tracking | |
electronic fence | |
ACC testing | |
6 months historical track | |
Offline alarm/Vibration alarm | |
Warranty | 24 months |
Common Functions
1.Real-time tracking
2.GPS+BD+LBS triple positioning
3.ACC detection
4.Cut off oil and power
5.Remote listening(Optional microphone)
6.SOS button(Optional SOS button)
7.Electric fence
8.Historical track
9.Car stop list
10.Call/SMS alarm
11.Vibration alarm
12.Speeding alarm
13.Remove the alarm
14.Multiple device management
Portable Mini GPS Tracker Over Speed Alarm GPS Tracker 2G 3G 4G G-sensor Car Vehicle GPS
Troubleshooting
1 If the terminal is unable to connect to the background server in the first time installation, background shows off line, please check the terminal installation
1.1 Check is the main power connection correct, pay attention not to connect to the vehicle interior control wire.
1.2 Is SIM card installed correctly, please refer to the installation instructions.
1.3 Please check is it power on, the switch at the back cover.
1.4 Check the LED status, please refer to the indicators instruction.
1.5 Check whether the GPS has been positioning, if not please go to the open air for the first time targeting.
requirements, please refer to the installation instructions.
generally the first time targeting needs 1-2 minutes.
5 When specific number receive power off SMS, check whether the illegal cutting line, otherwise check the power line fuse is broken, if so please
contact your dealer to replace the same types of specifications FUSE. After exclusion of the terminal and check internal fault, then we can turn on power to let the GPS continue to work.
Portable Mini GPS Tracker Over Speed Alarm GPS Tracker 2G 3G 4G G-sensor Car Vehicle GPS
Device wiring requirements
1 The device power supply is DC 9-100V. The red line is positive pole while the black line is negative pole.
2 The negative pole of power supply connects with ground or the metals. Please do not connect with other ground lines.
3 When finishing the power supply wire connection, please make the plug of power supply to the device
Any issue please contact the local distributors.
