C003-01-4G Model Anti Theft Device GPS Car Traker GPS GSM 2G 3G 4G GPS Tracking Device
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Track View:: | PC, IOS APP | Function: | Real Time Tracking |
|---|---|---|---|
| Feature: | Geo-fence, | Weight: | 50g |
| Type: | Mini 4G GPS Tracker | Certification: | ISO CE |
| Storage: | 32M RAM | Warranty: | 2 Years |
| High Light: | Geo Fence 4G GPS Tracker,FCC 4G GPS Tracker,GPS LBS Diagnostic Code Reader |
||
C003-01-4G Model Anti Theft Device GPS Car Traker GPS GSM 2G 3G 4G GPS Tracking Device
Product Parameters:
| Model | GT06 |
| Features | Vehicle malfunction diagnostics |
| Device Dimension | 90mm(L)*40mm(W)*15mm(H) |
| Weight | 50g |
| Quad Band | 850/1900/900/1800MHz |
| GPS Accuracy | 5-10m |
| Voltage Input | 9-100v |
| Hot Start<2S(Open Sky) | |
| Positioning Time | Warm Start<15S |
| Cold Start<32S(Open Sky) | |
| Tracking Sensitivity | -162dBm |
| GPS chip | MTK6261 |
Main function
| 1. Remote power off function | |
| 2. Real-time positioning function | |
| 3. Anti-theft alarm | |
| 4. Track playback function | |
| 5. Vibration alarm | |
| 6. Overspeed alarm | |
| 7. Electronic fence function |
C003-01-4G Model Anti Theft Device GPS Car Traker GPS GSM 2G 3G 4G GPS Tracking Device
Platform
| up to 180 days historical route track | electronic fence, out of the regional alarm |
| deviate planning route alarm | serious collision warning (optional); |
| rollover warning (optional); | overspeed alarm |
| report output | free to use |
Feature
| FDD LTE | 800/850/900/1800/2100/2600MHz |
| GPS positioning | GPS sensitivity: -162dBm |
| GPS positioning accuracy: 5 meters (under open conditions) | |
| Speed accuracy: 0.1 m/s | |
| Cold start time: <38 seconds | |
| Warm start time: <32 seconds | |
| Hot start time: <2 seconds | |
| Base station positioning | Support base station positioning, positioning accuracy: 10~200 meters |
| Working current | Average current ≈22mA (12vDC) maximum current <100mA (12VDC) |
| Operating temperature | -20~+70℃ |
| Material | Engineering plastics |
| Weight | 50G |
C003-01-4G Model Anti Theft Device GPS Car Traker GPS GSM 2G 3G 4G GPS Tracking Device
Device wiring requirements
1 The device power supply is DC 9-100V. The red line is positive pole while the black line is negative pole.
2 The negative pole of power supply connects with ground or the metals. Please do not connect with other ground lines.
3 When finishing the power supply wire connection, please make the plug of power supply to the device
Any issue please contact the local distributors.
Device status indicators
1 Connect DC 9-100V power supply and the red LED will light continuously.
The red LED is the power signal,
it is always on when the external DC is connected.
2 The blue LED is the GSM signal indicator.
It is always on when there is no GSM;
it flashes when GSM is normal;
it flashes quickly when transmitting data.
3 The yellow LED is the GPS signal indicator:
it is always on when there is no positioning;
it flashes after positioning.
C003-01-4G Model Anti Theft Device GPS Car Traker GPS GSM 2G 3G 4G GPS Tracking Device
Installation for the Car/Motorcycle/E-bike
The GPS tracker must be installed under professional personnel.
Note:
1) Please install the device in the hidden place as followings:
Under Front windshield；
In the front instrument panel；
Under back windshield；
2) Avoid being placed with signal radiators like reverse sensor ；
3) The device has GSM antenna and GPS antenna inside. Please ensure the receiving side of the device is face up and without metal cover.
Note:The metal cover will lessen the receiving of GPS signals.
How to tracking ?
The GPS devices support phone tracking.
Four types Tracking way:
A>: SMS + Map software;
B>: PDA Cell Phone;
C>: Real time tracking, and track via your computer;
D >: IOS and Android APP
