LTE 4G Car Vehicle Speed GPS Tracker For Automobiles

LTE 4G Car GPS Tracker Vehicle Speed Mini GPS Tracking Devices For Automobiles

GPS Vehicle Tracking

A GPS tracking unit is a device that uses the Global Positioning System to determine the precise location of a vehicle, person, or another asset to which it is attached and to record the position of the asset at regular intervals.

The recorded location data can be stored within the tracking unit, or it may be transmitted to a central location database, or any internet-connected computer, using a cellular ( GPRS), Radio, or a Satellite modem embedded in the unit.

 GPS Tracker Parameters:

LTE 4G Car GPS Tracker Vehicle Speed Mini GPS Tracking Devices For Automobiles

Hardware specifications

function name

Have no

Project function description

Electrical characteristics

Power supply

●

Battery-powered

Operating voltage range

●

DC 9V-95V

Working current

●

12V/average 35mA

Sleep current

●

12V/average 10mA

Built-in battery capacity

●

80 mAh (3.7V polymer battery) optional

Environmental characteristics

range of working temperature

●

-20℃-75℃

Storage temperature range

●

-30℃-80℃

Working humidity range

●

10%-85% RH non-condensing

Communication characteristics

Communication module brand/chip model

●

QUECHEE EC200

Communication frequency band

●

LTE/4G

LTE-FDD: B1/B3/B5/B8

LTE-TDD: B34/B38/B39/B40/B41

3G

WCDMA :B1/B5/B8

TD-SCDMA: B34/B39

GSM/EDGE/2G

B3/B8

SIM card

●

Micro SIM card

Communication antenna

●

Built-in antenna

Antenna specification

●

FPC antenna

Manager Features

1. Real-Time Positioning:

GPS Tracker Device will get the real-time position message and upload all status to the server system.

And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. speed

GPS Time, direction, and so on.

2. Vibration alarm:

After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.

3. Power-off alarm:

If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.

4. Remote Car Lock

If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.

Main functions:

1. Precise GPS positioning

2. Support 808 standard agreement

3. Remotely cut off oil and electricity

4. DC detection

5. Power failure alarm

6. Speeding alarm

7. Electronic fence

8. Track playback

9. Vibration sensing

10. ACC testing

11. Vehicle speed detection
