Voltage: | 9-36V | Warranty: | 2 Years |
---|---|---|---|
Brand Name: | YTWL Or Blank | Size: | 117*92*31 (mm) |
Backup Battery: | 1000mAH | Application: | Car Truck Bus Taxi Van |
GPS Accuracy: | 5-10 Meters | Function: | Speed Control, Vehicle Speed Limit |
High Light: | Speed Sensor Forklift Speed Limiter,1000mAH Forklift Speed Limiter,36V Car Speed Limiter |
Forklift Speed Limiter With Speed Sensor Alarm Realtime Tracking Via Mobile APP
YTWL speed limiter CA-100F is a car speed limiter with tracking and positioning function, which meets the standards of ES6413, and is widely used in Ethiopia markets. Whether it is an electronic throttle or a mechanical throttle vehicle, we have a complete solution. Don't worry that the engine will stop the engine when the speed limiter device is working. The relay delay function can ensure that the car can also drive normally during the speed limit process. The device can extract speed data through the computer, which can provide strong evidence for the effective supervision of government departments. We provide a 2-year warranty for the gps speed limiter device.
Technical Parameter:
Content | Specs. |
Dim. | 117*92*31 (mm) |
Weight | 280g |
Network | GSM/GPRS/GPS |
Band | 850/900/1800/1900MHz |
GPS chip | U-blox |
GSM/GPRS Module | SIM800C |
Bluetooth Module | BT360I |
CPU | STM32F105RBT6 |
Power IC | TD1509-ADJ |
Anti-jamming | Strengthened Anti-jamming |
GPS sensitivity | -159dBm |
GPS accuracy | 5 m |
Description:
1. tamper Protection Mode(disconnect signal wire / power wire,into limp model).
2. speed record on board and off board ( Date & Time, Speed, Highest speed, Violation).
3. limiter device can resistant to reverse polarity connections.
4. over speed alarm & pre-warn alarm. this warning occur at 5% prior to the set speed and continue buzzing once the set speed is achieved / exceeded.
5. real time tracking through web tracking platform and cell phone app.
6. limiter device upload the data at not more than 10seconds interval.
7. limiter device can store the data in a non-erasable memory for at least 72 hours even if the power supply is disconnected.
8. portable printing be supported, can print out 1hour / highest speed / violation record.
Forklift Speed Limiter With Speed Sensor Alarm Realtime Tracking Via Mobile APP
Inbuilt Relay GPS Speed Limiter is a speed governor recorder to limit a maximum speed to a safe speed with no effect on the normal operation of vehicle.
It's a mandartory enforcement Speed Limit Device according to African countries' Transportation Authority Standard.
As we all know, over-speeding is the major cause of accidents in our roads and we have to look for all possible ways in curbing this menace.
Speed control is necessary to reduce accidents in the roads. Except that, we also need to know the details of the cars, like current location, speed, etc, and then when accident occur, we can offer help in time.
At this time, GPS Tracking Speed Limiter will help for African Governments Transporation Authorities Implementations.
African Government Approved Ethiopian GPS Vehicle Speed limiter GPS Limiting Speed For School Bus /Cars
GPS Speed Limiter.It will limit a maximum speed to a certain speed that you want. You may be able to preset the max.speed by remote controller or our computer software.
Geography fence speed limit. Different areas, differernt speed limit value.
Data will be recorded
Speed Limit Range: 10km/h-120km/h
Printing violation record
Mileage report ( It can calculate how many kilometers do the vehicles go every day )
Can force to limit the speed intelligently, safe speed limit.
Temper proof speed governor
Automatic speed calibration or by remote calibrator.
Maximum pre-set speed can be set by administrator.
Can record the data between 72 to 360 working hours( speed record, longitude, latitude,strength of GPS signal, year, month, day, hour, munite, second, the speed of vehicle)
Data retrieval of speed record from the device.
Can be directly on the software to see the tracking of speed, and tracking playback can also be viewed on the Google map.
Strong stability
Easy to install
Voltage: DC9V to DC 36V
Programmable
Support Mechanical and Electronic accelerator pedal speed limitator
Real time GPS tracking
Online fleet management, etc
On Live Platform for fleet management.
Competitive price
