Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence

Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence
Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence

Large Image :  Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence Get Best Price

Product Details:
Place of Origin: China
Brand Name: cartrack
Certification: CE/ROHS/FCC/SGS
Model Number: CA100F
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 100,000pcs per month
Contact Now
Detailed Product Description
Product Name: CA100F Speed Limiter Processing Chip: ARM
GPRS: Class12, TCP/IP GPS: Built In
Remote Monitoring: Support Oil Controlling: Support
Geo-fence: Support Movement Alert: Support
Remote Monitoring: 5m
High Light:

vehicle gps tracking device

,

car gps tracker device



Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence



1 Speed Limiter GPS Product Specifications



Color Black
Input Fuse 5A
Battery Lithium battery :400mA( working time is about 3.5 hours)
Item Name Top selling shine
Working Temperature Anna Shi
GSM Module GSM Module:SIM5320
Band:850/900/1800/1900/2100MHz,
Tally with: GSM phase 2/2+
-Class 4 (2W @ 850/900MHz)
-Class 1 (1W @ 1800/1900MHz)
Max RF Output: 33.0dBm±2dBm
Dynamic Input Range: -15 ~ -102dBm
Receiving delicacy: Class RBER≤2%(-102dBm)
Frequency Stability: > 2.5ppm
Max Frequency Deviation: ±0.1ppm
RMS Deviation: ≤5deg
GPS SMS Command list
  1. Check Device Status :STATUS#
  2. Check Device parameters :PARAM#
  3. Check GPRS Parameters :GPRSSET#
  4. Check Device Lat. And Log. :WHERE#
  5. Check Server parameters :SERVER#
  6. Reset Device :RESET#
  7. Add SOS Number :SOS,A, Number 1,Number 2,Number 3#
Application free android and IOS app
CPU TI:MSP430F5419(100MHz)
Warranty 2 years
Function camera gps fleet tracker
MOQ 10 Pieces
GPS Module GPS chip set: SiRF Star III
Frequency: L1, 1575.42 MHz
Number of Channel: 20
Reacquisition: 0.1 sec, average
Hot boot: 2 sec., average
Warm boot: 38 sec., average
Cold boot: 44 sec., average
Altitude limit: 18000 m
Velocity limit: 515 m/s











































2. Speed Limiter Requirement

Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence



  1. The speed limiter device systems shall be "failsafe" in such a way that if the plug/s to the electronic controller is/are removed, power is disconnected or if the speed signal and/or wire is disconnected the vehicle shall automatically, default to a limp mode or the engine shall stall or return to idle or, at least, and thus shall not be able to be driven in excess of thirty kilometers per hour. (30km/h).
  2. For the purpose of anti-tampering of the setting of the "set speed" of a speed limiter device, the connection points on a speed limiter device for adjustment of "set speed" shall be properly sealed and protected from unauthorized adjustment.
  3. The actuation force of the controls should not have a detrimental effect on the driver's efficiency or impose fatigue on the driver;
  4. The speed limiter function or road speed limiter shall be EMCcompatible or shall have Anti-Jammer mechanism
  5. The speed limiter function shall be obtained once the vehicle speed reaches the set maximum speed regardless of the position action on the accelerator a driver may apply.
  6. The speed limiter function or the road speed limiter shall not cause uncontrolled engine power.
  7. The speed limiting device shall be so designed, constructed and assembled so as to resist vibrations, corrosion, dust, humidity, petrochemicals and aging phenomena to which it may be exposed.

3.Speed Limiter Control Circuit



Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence

    Send SMS “stopelec+password” to control circuit. For example send SMS: “stopelec123456”."stopoil" as instructions, "123456" as the password.To supply the circuit again, send SMS “supplyelec+password” to the unit. For example, send SMS “Supplyelec123456” to the tracker. "Supplyelec" as instruction, "123456" as password.

4.Speed Limiter GPS GPRS GSM Main functions
  1. Positioning and Tracking: Through the on-line Positioning Platform or the cell phone to locates at times, and get the working status. You can choose the Positioning Platform by yourself.
  2. Geo-fence: Set up a geo-fence for the unit to restrict its movements within a district. The unit will send the message to all authorized numbers when it breaches the district
  3. Remote Monitoring: In anywhere and anytime, call the phone number in the unit, when it connects, you can monitor the sound around 5 meter.
  4. Movement Alert: Send SMS to the unit to start the movement alert function. When the vehicle is moving, the unit will send the movement alert to all authorized numbers.
  5. Mileage statistics; ACC checking; cutting off power and alarm.



5  Application Field:

  1. For School Bus ;
  2. For tour bus and passenger car management ;
  3. For logistics vehicle monitoring and management ;
  4. For tank truck monitoring and management.
  5. For limit the speed of vehicles

Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence 0Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence 1Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence 2Ethiopia Motor GPS Speed Limiter Fuel Sensor Controlling Fuel Level GPS Geo-fence 3
