Product Details:
Payment & Shipping Terms:
|
| Product Name: | CA100F Speed Limiter | Network: | GPRS GSM |
|---|---|---|---|
| Band: | 850/ 900/1800/1900MHz | Application: | Buses Trucks Forklifts |
| Work Voltage: | DC12V-DC60V | GPS Sensitivity: | -159dBm |
| Alert: | Overspeed Alert | LED Indicator: | 4G(blue), GPS(green), Power(red) |
| Processing Chip: | STC | Speed Limiting Zone: | 20-200 Km/H |
| Speed Limiting Deviation: | ±5Km/H | ||
| High Light: | vehicle gps tracking device,electronic engine governor |
||
Mexico Car Vehicles Speed Limiter With GPS GPRS Functions For Trucks Forklifts
Main Features:
| Brand | N-EC |
| Model | NXS-3 |
| Warranty | 12months |
| Place of origin | Guangdong, China (Mainland) |
| Working Voltage | 9-36V |
| Applicable temperature | -20°C~70°C |
| Rated power dissipation | 2W |
| Certificate | SONCAP,CE,FCC,KEBS |
| Speed limiting range | 1 to 200km/h |
| With Recording function | Yes |
| Test | 100%tested before delivery |
| Application | All kinds of vehicles |
| Size | 140mm*87mm*38mm |
| Be controlled by | The administrator not the driver |
| Programmable | Yes |
| Waterproof & Tamperproof | Yes |
Function:
Speed Limiting: It’s able to limit the vehicle speed within the controllable range.
(1)Record data:
A. History data recording within 72 hours, including: Speed,License No.,Odometer, Date&Time, Driver ID No., etc.
B. Support retrieving history data from USB port.
(2)Parameter query & setting:
All parameters can be set directly in computer, and each device can be programmed through an USB flask disk, which is tamp-proof and need password.
(3)Tachograph & Speed Limitation function
When the vehicle speed is close to pre- set speed limit value (default 80km/h) , the speed limiter will issue a " beep, beep ... " sound alarm to remind drivers to slow down. If drivers do not slow down , it automatically starts to reduce throttle actuator , until the speed drops to restore the driver to control the throttle. Meanwhile, the speed limiter willrecord the driver code , license plate numbers , overspeeding time etc.
(4) Display Screen to show real time data and parameter details
(5) Police unit to program
1. Product Brief:
The vehicle speed limiter CA100F is a vehicle terminal device can make accurate and intelligent vehicle speed Limiting. It can judge the vehicle speed by vehicle pulse speed data and GPS speed data precisely, and control the vehicle speed by intervening the throttle valve opening size.The user can set the speed limit value through the external digital display controller .
The product adopts intelligent STC chip, with high control precision, stable and reliable, will not affect the starting throttle, not affect the dynamic torque, only limit the maximum speed of the vehicle, control the throttle valve but will not lead to stalling, can ensure the throttle pedal can move freely in the allowable speed zone. It is a powerful and efficient intelligent vehicle safety products.
2. Product Function:
Mexico Car Vehicles Speed Limiter With GPS GPRS Functions For Trucks Forklifts
3. Technical Parameters:
Mexico Car Vehicles Speed Limiter With GPS GPRS Functions For Trucks Forklifts
4 The Mechanical Actuator
For the Electronic throttle ( EFI ) vehicles , no need add mechanical actuator, the limiter will simulate the voltage value of the vehicle throttle sensor, when the vehicle is over speed, The limiter will give ECU a idle voltage value, ECU will control the throttle according to this voltage value. When the vehicle is in normal driving state(not over speed), the speed limiter will not interfere the vehicle speed. The throttle sensor will give ECU normal driving voltage, let the vehicle keeping normal driving.
7 Application Field:
Q1. Are you manufacturer?
Answer: Yes, we are the top manufacturer for IC chip, Sound Module, Speed Limiter, Greeting Doorbell, Sound Light Alarm, Animal Repeller Such as bird repeller, mice repeller, monkey repeller, ants repeller and mosquito dispeller in China. Availability over 10 thousand one month.
Q2. How can I make payment?
Answer: We accept payment via T/T, western union and Paypal at sight.
Q3. What should I do if the products have some quality problem?
Answer: Within warranty period, if it is not man-made problem, we will offer you free replacement accessories
Q4. Can I order one piece for sample to test the quality?
Answer:Yes, We would like to offer you sample to test our quality and we recommend to check the sample before order.
Q5: Why choose N-EC? Any advantages?
Answer:
(1) MUTUAL BENEFIT: Our offer will be reasonable, our price will be cheaper in the same quality.
(2) CUSTOMIZE: We can make the product as your request.We have Excellent engineers and skilled workers, can work out one to three new products to update our catalog every two months. We can also customize a new item for you within 20 days.
(3) OEM: (1)Print your Logo. (2)Design your packing box.
(4) MIX ORDER: We accept mix order, different model and small quantity order.
(5) AFTER SERVICE: (1) 12 Months Guarantee. (2)If some parts are broken, we will send new parts to repair after confirmed.
