Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Function: | Real Time Tracking | Place Of Origin:: | Shenzhen China |
|---|---|---|---|
| Model Number: | C003-01-4G GPS TRACKER | Color: | Black |
| Working Humidity: | 20%～80%RH | Battery: | Built-in 200mAh |
| Use: | Automotive | Type: | 4G GPS Tracker |
| High Light: | GSM Vehicle Camera GPS Tracker,4G LTE Connectivity GPS Tracker |
||
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
| FDD LTE | 800/850/900/1800/2100/2600MHz |
| GPS positioning | GPS sensitivity: -162dBm |
| GPS positioning accuracy: 5 meters (under open conditions) | |
| Speed accuracy: 0.1 m/s | |
| Cold start time: <38 seconds | |
| Warm start time: <32 seconds | |
| Hot start time: <2 seconds | |
| Base station positioning | Support base station positioning, positioning accuracy: 10~200 meters |
| Working current | Average current ≈22mA (12vDC) maximum current <100mA (12VDC) |
| Operating temperature | -20~+70℃ |
| Material | Engineering plastics |
| Weight | 50G |
| Network | 4G LTE/3G WCDMA /2G GSM |
| Dim. | 90*40*15mm |
| Storage Temp. | -40°C to +85°C |
| Accuracy | 5-20m |
| Operation Temp. | -20°C to +55°C |
| Humidity | 20%--80% non-condensing |
| Working Voltage | 9-100V |
| CPU | MTK6261 |
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Parameter
| Size | 90(L)×40(W)×15(H)mm |
| Working temperature | -20℃～+70℃ |
| Working Voltage | DC9-100V |
| Weight | 50g |
| Built-in Battery | 200MAH |
Hardware Specification
| Location Accouracy | 10M |
| GPS Chip | MT6261 |
| FDD-LTE Frequency | 800/850/900/1800/2100/2600MHz |
| GPS antenna | Built-in,18*18*4 mm |
| GPRS | Class12 TCP/IP |
Software Specification
| ACC Detection | support |
| GEO-fence | support |
| Cut power | support |
| Vibration | support |
| Movement | support |
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
Indicators
Red light - Power Indicator / OBD Work Lights
| LED Status | Meaning |
| Flash once in 2 seconds | Normal operation / OBD working properly |
| No light | Shutdown / OBD sleep |
Yellow indicator light -GSM
| LED Status | Meaning |
| Flash once in 2 seconds | GSM initialization |
| Light Always | GPRS is normal / already online |
| No light | GSM sleep |
Blue LED light -GPS
| LED Status | Meaning |
| Flash once in 2 seconds | GPS signal searching |
| Light Always | GPS targeted |
| No light | GPS sleep |
Proper Use of The Product
Install→Power on→Settings→Register
Installation: GPS antenna should be facing toward the sky, above the mounting location must be no material (such as metal, window film) absorption of electromagnetic waves sheltered place.
Boot: Insert the SIM card correctly, connect the wire according to diagram, then turn on the power.
Setting: Must be done, or can not do other operations, mobile phone owners send text messages to set the owner number and a specific number to the terminal SIM card.
Registration: Registration method is different subject to dealer platforms, please consult your dealer.
Mini Portable 4G GPS Tracking Car Vehicle Ebike GPS Trackers with Moving Alarm Geo-fence
FAQ
Q:How about the quality of 4g GPS tracker ?
A :We produce every product with good quality materials and fully test three times before shippment. What is more, our quality areapproved by CE RoHS SGS & FCC, IOS9001, BSCI.
Q: Can i have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: What is the lead time?
A: Sample needs 1 working days, mass production needs 5-15 working days depends on order quantity.
Q: Can I put order with PayPal for a fast shipment?
A: Sure, we support both alibaba online orders and Paypal, T/T, Western Union offline orders. Please contact us for details.
