Easy Operation and installation GPRS Tracker with GPS Antenna and Protocol GT06 4G GPS Tracker
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Warranty: | 2 Years | Use: | Automotive |
|---|---|---|---|
| Network: | FDD-LTE | GPS Chip: | MT6261 Chip |
| GPS Accuracy:: | 5-10M | Application: | Mini 4G GPS Tracker |
| Certificate: | ISO CE | Type: | 4G GPS Tracker |
| High Light: | GSM Vehicle Camera GPS Tracker,4G LTE Connectivity GPS Tracker |
||
Easy Operation and installation GPRS Tracker with GPS Antenna and Protocol GT06 4G GPS Tracker
| SMS Command list | |||
| NO. | Item | SMS Commands format | Remarks |
| 1 | Check Device Status | STATUS# | |
| 2 | Check Device parameters | PARAM# | |
| 3 | Check GPRS Parameters | GPRSSET# | |
| 4 | Check Device Lat. And Log. | WHERE# | |
| 5 | Set Server IP or Domain name |
SERVER,1,domain name,port,0#
SERVER,0,IP,Port,0# The last bit 0 stands for TCP |
|
| 6 | Check Server parameters | SERVER# | |
| 7 | Reset Device | RESET# | The terminal will restart after 1 minutes |
| 8 | Add SOS Number | SOS,A, Number 1,Number 2,Number 3# | |
| 9 | Del SOS Number | SOS,D,No. 1,No. 2,No. 3# | |
| 10 | Check SOS Number | SOS# | |
Easy Operation and installation GPRS Tracker with GPS Antenna and Protocol GT06 4G GPS Tracker
Paremeter
| Working voltage | DC 9～40 V |
| Working temperature | -20℃～+70℃ |
| Storage temperature | -40℃～+85℃ |
| Working humidity | 20%～80%RH |
| Main Chip | MT 6261 |
| GPRS Module | MTK high sensitivity chip |
| Tracking sensitivity | -160dbm |
| Location accuracy | <10m |
| GSM frequency | 2G:GSM 850MHz,900MHz,1800MHz,1900MHz 3G WCDMA 2100/1900/900/850MHz 4G:FDD-LTE 800/850/900/1800/2100/2600MHz |
| Device weight | 50g |
| Device dimension | 90mm*40mm*15mm |
Main Feature:
| * 4G 3G 2G bands |
| * Built-in acceleration sensor for vibration alarm and power saving |
| * Built-in battery, power disconnection alarm function |
| * Super wide working voltage input range: 9-100V |
| * The ACC ignition signal detection, vehicle status indicators |
| * SMS Arm / Disarm |
| * Watchdog function, reboot automatically after breakdown |
| * Suitable for Vehicles/Cars/Motorcycles/E-bike etc |
| * SOS ,microphone ,Relay is optional |
Easy Operation and installation GPRS Tracker with GPS Antenna and Protocol GT06 4G GPS Tracker
Main function
| Real-time tracking | GPS+BD+LBS triple positioning |
| ACC detection | Cut off oil and power |
| Electric fence | Historical track |
| Call/SMS alarm | Vibration alarm |
| Speeding alarm | Remove the alarm |
| Remote listening (Optional microphone) |
SOS button (Optional SOS button) |
Car stop list
Through the APP, you can check where the vehicle has parked for a period of time in the past
Call/SMS alarm.
You can set a center number, and when the tracker detects an alarm message, it will call your center number. You can also set the SOS number, and the tracker will send a text message to your number when it detects an alarm message.
Vibration alarm.
After arming through the APP, when the vehicle detects vibration, it will send you an alarm message.
Principle of Vibration Alarm.
There is a vibration sensor in the gps tracker. When the sensor detects the device vibration, it will send out an alarm message. The change function is more sensitive and is used for vehicle anti-theft. It is recommended to turn off when the vehicle is driving.
Speeding alarm.
Set a speed. When the vehicle speed exceeds this value, an alarm message will be issued.
Remove the alarm.
The device has a built-in battery, and there will be a power failure alarm when the main line is cut off.
Easy Operation and installation GPRS Tracker with GPS Antenna and Protocol GT06 4G GPS Tracker
Q1:How can I get more information about your product?
A1:You can send us an email or ask our online representatives and we can send you the latest catalog and price list.
Q2:What is the payment way of your company?
A3:T/T or western Union or paypal
Q3:What is the shipping way?
A4:By sea,air,Fedex,DHL,UPS,TNT etc.
Q4:How long for manufacturing once we place order?
A5:It's about 5-10 days after payment or disposit.
