GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker

Large Image : GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Cartracker
Certification:	CE ISO9000
Model Number:	C003-01-4G

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	negotiation
Packaging Details:	Packed in carton firstly
Delivery Time:	1-10 working days after received your payment
Payment Terms:	T/T or western Union or paypal
Supply Ability:	10,000pcs per month

Contact Now

Detailed Product Description

Function:	Realtime Tracking	Place Of Origin::	Shenzhen China
Application:	Real-time Tracking	Battery:	200mAH
Model No::	C003-01-4G	Color:	Black
Keyword:	4G/3G/2G GPS Tracker	Feature:	Car Anti-theft
High Light:	Geo Fence 4G GPS Tracker , FCC 4G GPS Tracker , GPS LBS Diagnostic Code Reader

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker

Product description

Working voltage	DC 9～40 V
Working temperature	-20℃～+70℃
Storage temperature	-40℃～+85℃
Working humidity	20%～80%RH
Main Chip	MT 6261
GPRS Module	MTK high sensitivity chip
Tracking sensitivity	-160dbm
Location accuracy	<10m
GSM frequency	2G:GSM 850MHz,900MHz,1800MHz,1900MHz 3G WCDMA 2100/1900/900/850MHz 4G:FDD-LTE 800/850/900/1800/2100/2600MHz
Device weight	50g
Device dimension	90mm40mm15mm

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker 0

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker

Equipment parameters:

Electric Speicifications

Power supply mode: Battery power supply

Working voltage range: DC 9V - 100V

Working current: 12mA (24vDC)

Built-in battery capacity: 200mAH

Environmental Features

Working temperature range -20℃ - 70℃

Storage temperature range, low - 30 ℃ -80 ℃

Working humidity range - 20%-80%RH

Communication frequency band
LTE	FDD-LTE :B1/B3
	TDD-LTE :B38/ B39/ B40/ B41
3G	WCDMA:B1
	TD-SCDMA:B34/B39
	EVDO/CDMA2000 1x :BC0
GSM/EDGE	B3/B8

Communication antenna - built-in antenna

GPS/LBS Positioning Characteristics

Cold start time - average 34 seconds

Hot start time - average 2 second

Sensitivity (tracking) -162DBM

Positioning antenna - built-in antenna

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker 1

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker

4G Band

Europe / Middle East / Africa / South Korea / Thailand EC25-E:	LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8
North America EC25-A EC25-V	LTE FDD: B2/B4/B12 WCDMA: B2/B4/B5 LTE FDD: B4/B13
Australia/New Zealand/Taiwan/Brazil EC25-AU	LTE FDD: B1/B2*/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8
Japan EC25-J	LTE FDD: B1/B3/B8/B18/B19/B26 LTE TDD: B41 WCDMA: B1/B6/B8/B19

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker 2

GT06 Mini Vehicle GPS Tracker Real Time Tracking Device SMS+LBS Locator 4G GPS Tracker

Installation for SIM of device
Preparation for the installation
1.1 Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer.
1.2 Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference.
1.3 SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder.
1.4 Put back the front cover and screw it up.
1.5 Connect the device to the 9-100Vpower supply.(the red LED constant glow)
1.6 Install the device in the hidden place of the car；

The SIM card must be with GPRS function and enough deposit. If your SIM card need input PIN when power on, please cancel it.

How to tracking ?

The GPS devices support phone tracking.

Four types Tracking way:

A>: SMS + Map software;

B>: PDA Cell Phone;

C>: Real time tracking, and track via your computer;

D >: IOS and Android APP

What is your cell phone number?

My mobile phone number / WhatsApp is +8613717161241. Wechat is 008613717161241
