4G GPS Tracker real time Checking Car GSM GPRS GPS tracker Device Support platform app search
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Function: | Real Time Tracking | Connection: | 3G/4G Sim Card, 2G Sim Card |
|---|---|---|---|
| Certification: | ISO9000 CE | USE: | Automotive |
| Product Name:: | 4G GPS Mini Tracker | Location Way:: | GPS+SMS |
| Battery: | 200mAH | Type: | GPS Tracker |
| High Light: | Geo Fence 4G GPS Tracker,FCC 4G GPS Tracker,GPS LBS Diagnostic Code Reader |
||
4G GPS Tracker real time Checking Car GSM GPRS GPS tracker Device Support platform app search
4G GPS Tracker real time Checking Car GSM GPRS GPS tracker Device Support platform app search
Descriptions:
| FDD LTE | 800/850/900/1800/2100/2600MHz |
| GPS positioning | GPS sensitivity: -162dBm |
| GPS positioning accuracy: 5 meters (under open conditions) | |
| Speed accuracy: 0.1 m/s | |
| Cold start time: <38 seconds | |
| Warm start time: <32 seconds | |
| Hot start time: <2 seconds | |
| Base station positioning | Support base station positioning, positioning accuracy: 10~200 meters |
| Working current | Average current ≈22mA (12vDC) maximum current <100mA (12VDC) |
| Operating temperature | -20~+70℃ |
| Material | Engineering plastics |
| Weight | 50G |
| Network | 4G LTE/3G WCDMA /2G GSM |
| Dim. | 90*40*15mm |
| Storage Temp. | -40°C to +85°C |
| Accuracy | 5-20m |
| Operation Temp. | -20°C to +55°C |
| Humidity | 20%--80% non-condensing |
| Working Voltage | 9-100V |
| CPU | MTK6261 |
4G GPS Tracker real time Checking Car GSM GPRS GPS tracker Device Support platform app search
Installtion
Terminal installation is concealed installation, hidden installation recommendations terminal equipment designated by the distributor of professional and technical personnel to install, note the following:
1 To avoid damage to the thief, the device select bits should be hidden;
2 To avoid to put the emission sources together, such as reversing radar, anti-theft devices and other automotive communications equipment;
3 It can be fixed by cable ties, or use wide sponge double-sided adhesive stickers;
4 Equipment built-in GSM antenna and GPS antenna, the installation should ensure a positive upward (toward the sky), and the above non-metal shield block, the proposed installation location:
(1) Below the windshield inside the decorative panel;
(2) Car meter (surface of non-metallic materials) around the shelter;
(3) Rear windshield below the decorative panel;
(4) Inside car door or pillar;
(5) Within the dashboard or under back seat hidden
Note: (1) If below the windshield there is metal insulation or heating layer will reduce the GPS signal reception, causing the GPS malfunction, please change the installation position;
(2) Some models are built-in 3D sensor, and it needs to detect acceleration, deceleration and rollover, equipment must be installed according to the mounting direction front and rear direction of the vehicle can not be mounted transversely.
4G GPS Tracker real time Checking Car GSM GPRS GPS tracker Device Support platform app search
Warranty
In particular that:
1. Any technical changes to the product in the future without prior notice.
2. Any changes of appearance, color of products, to prevail in kind.
3. The warranty card is only available in the following listed IMEI / ID Number warranty Services.
4. Please keep this service card, please show this card and the original purchase receipt for warranty.
5. See the table below illustrate specific warranty.
This card is a basic warranty certificate, user please fill out the card and keep it.
| Name | TEL | ||
| Model | IMEI/ID NO. | ||
| Purchase Date | Invoice NO. |
