SMS Text Location for 4G GPS Tracker with SOS Button Optional
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Working Voltage: | DC9-100V | Place Of Origin: | Shenzhen China |
|---|---|---|---|
| Located Way:: | GPS+LBS | Type: | GPS Tracking |
| Accuracy: | 5-10M | Operating Temperature: | -20℃ ~ +70℃ |
| Networks: | GSM/WCDMA/FDD LTE | Use: | Automotive |
| Function: | Over Speed Alarm | ||
| High Light: | 4G LTE Vehicle GPS Tracker,ACC Input Detection GPS Tracker,LBS Positioning GPS Tracking Device |
||
SMS Text Location for 4G GPS Tracker with SOS Button Optional
Frequently used commands:
| Command | Explain | Reply content |
| IMEI# | IMEI query | IMEI: 116790246811200 |
| IMEI,116790246811200# | Set IMEI | OK |
| FACTORY# | Restore factory settings | OK, The terminal will restart after 30 seconds! |
| RESET# | restart | The terminal will restart after 1 minute! |
| WHERE# | Location query | Current position!Lat:N22.589031,Lon:E113.853567,Course:0,Speed:0,DateTime:2018-07-26 10:25:55 |
| URL# | Google link query |
GPS! N4.85094 E7.06102 speed:000.0 T:07/13/19 11:37 http://maps.google.com/maps?q=N4.864553,E6.983681 |
| SERVER# | Server query | server,1,gw.carhere.net,8005,0# |
| server,1,gps-go.com,6006,0# | Set domain name | ok |
| Server,0,121.201.110.106,6006,0# | Set IP | ok |
| GMT# | Time zone query | Currently Timezone(GMT):E,8,0 |
| APN# | APN query | Currently in use APN:peoples.net,0000,0000; |
| APN,xxxx# | Set APN | |
| APN,xxxxt,userAAA,passBBB# | Set apn and apn user,password | Example: apn,cmnet,aaa,000# |
|
GMT,<A>,<b>[,C]#
example, GMT,E,8,0#
|
Change time zone command |
A:E/W, E east time zone, W west time zone, default: E B: 0～12; time zone, default value: 8 C: 0/15/30/45, half time zone, default value: 0
|
SMS Text Location for 4G GPS Tracker with SOS Button Optional
| 2G | GSM 850MHz,900MHz,1800MHz,1900MHz |
| 3G | WCDMA 2100/1900/900/850MHz |
| 4G | FDD-LTE 800/850/900/1800/2100/2600MHz |
| Detail | |
| Operating voltage | DC9-90V |
| Operating current | 22mA@12V |
| Specifications | L90mm*W40mm*H15mm |
| Positioning mode | GPS, LBS and positioning |
| Positioning error | < 10 m |
| Support WCDMA | Yes |
| Communication | TCP |
| Operating temperature range | -20℃～+70℃ |
| Storage temperature range | -40℃~+85℃ |
| weight | 50g |
SMS Text Location for 4G GPS Tracker with SOS Button Optional
Device status indicators
1. Connect DC 9-100V power supply and the red LED will light continuously.
The red LED is the power signal,
it is always on when the external DC is connected.
2. The blue LED is the GSM signal indicator.
It is always on when there is no GSM;
it flashes when GSM is normal;
it flashes quickly when transmitting data.
3. The yellow LED is the GPS signal indicator:
it is always on when there is no positioning;
it flashes after positioning.
Installation for SIM of device
Preparation for the installation
1 Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer.
2 Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference.
3 SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder.
4 Put back the front cover and screw it up.
5 Connect the device to the 9-100Vpower supply.(the red LED constant glow)
6 Install the device in the hidden place of the car；
SMS Text Location for 4G GPS Tracker with SOS Button Optional
When in emergency situation need help, you can press the SOS to trigger SOS emergency alarm. Device will send a SOS message to specific number and call the specific number until pick up. Device will also send SMS alarm information to platform.
When the vehicle thefts, by monitoring background to send off fuel directive, to ensure the vehicle is in safe driving premise, cutting stolen vehicle fuel, unable to start the vehicle to achieve the purpose.
Logistics companies can be set by the software to monitor the goods is notified of the departure time, route point, line alarm, warning area, heavy hit the alarm, rollover warning, driving speed, etc., we will comprehensive analysis of goods in transit situation and issue reports.
Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;
Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;
Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.
Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;
Q5: How about your platform cost?
Re: Free for lifetime;
