Product Details:
Payment & Shipping Terms:
|
Model Number: | C003-01-4G | Color: | Black |
---|---|---|---|
Working Humidity: | 20%~80%RH | Network: | 4G/3G/2G |
Function: | Tracking | Working Voltage: | DC9-100V |
Size: | 90(L)×40(W)×15(H)mm | Warranty: | 2 Years |
High Light: | 4G LTE Vehicle GPS Tracker,ACC Input Detection GPS Tracker,LBS Positioning GPS Tracking Device |
Mini 4G GPS Tracker for Car Vehicle Tracking Device with Moving Alarm C003-01-4G Model
Produce Description
GSM | GPRS |
Geo-sensor | Input power |
ACC | Ignition checking |
Built-in battery | Cutt off power/fuel |
Real time tracking | Over speed alarm |
Relay supported | Platform /APP supported |
Content | Specs. |
Dim. | 90 mm x40 mm x 15 mm |
Weight | 50g |
Network | GSM/GPRS/GPS |
Band | 850/900/1800/1900 MHz |
GPS chip | U-B |
GSM module | MTK6261 |
GPS accuracy | 10m |
GPS locating time | Cold start≈38s(Open sky) |
Warm start≈32s(Open sky) | |
Hot start≈2s(Open sky) | |
Work voltage | DC9V-100V |
Storage Temp. | -40°C to +85°C |
Humidity | 20%--80% |
Mini 4G GPS Tracker for Car Vehicle Tracking Device with Moving Alarm C003-01-4G Model
Platform
up to 180 days historical route track | electronic fence, out of the regional alarm |
deviate planning route alarm | serious collision warning (optional); |
rollover warning (optional); | overspeed alarm |
report output | Free to use |
Features
Remote cut-off (petrol/power) | Light and compact |
Compel the vehicle to stop by breaking off the fuel connection | Small size allowing covert & easy mounting |
ACC detection | GPS + LBS Positioning |
Be aware of the ignition status where you need | Allow the location to be pinpointed in real time |
Tracked by: SMS, APP, Web | voltage range:9-100V |
Reports location in real time through different interfaces | Voltage adaptation up to 100v |
Mini 4G GPS Tracker for Car Vehicle Tracking Device with Moving Alarm C003-01-4G Model
Frequency:
Europe / Middle East / Africa / South Korea / Thailand EC25-E: |
LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8 |
North America EC25-A EC25-V |
LTE FDD: B2/B4/B12 WCDMA: B2/B4/B5 LTE FDD: B4/B13 |
Australia/New Zealand/Taiwan/Brazil EC25-AU |
LTE FDD: B1/B2*/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
Japan EC25-J |
LTE FDD: B1/B3/B8/B18/B19/B26 LTE TDD: B41 WCDMA: B1/B6/B8/B19 |
2G:GSM 850MHz,900MHz,1800MHz,1900MHz
3G WCDMA 2100/1900/900/850MHz
4G:FDD-LTE 800/850/900/1800/2100/2600MHz
Mini 4G GPS Tracker for Car Vehicle Tracking Device with Moving Alarm C003-01-4G Model
Preparation for the installation
1 . Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer.
2 . Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference.
3 . SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder.
4 . Put back the front cover and screw it up.
5 . Connect the device to the 9-100Vpower supply.(the red LED constant glow)
6 . Install the device in the hidden place of the car;
FAQ:
Q:Haw can i buy it? |
A:We accept T/T,Westem Uniton and Paypl.After we recerive your payment. |
Q:Can we put into my motorcycle? |
A:Yes,of course!it support DC9-100V voltage input for any vehicles. |
Q:Can we use your platform? |
A:yes,you can use our platform.And it is free to use. |
Q:What is the lead time if we place order to get the parcel? |
A:It needs 1-10 working days after received your payment |
