Warranty 2years 4G GPS Tracking Device Remote Monitor Voice Smart GPS Tracker
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Use: | Automotive | Customization1: | Logo |
|---|---|---|---|
| Customization2: | Shell Color | Network: | FDD 800/850/900/1800/2100/2600MHz |
| Placement: | Instument Panel | Function: | Remotely Monitoring |
| Warranty: | 24 Month | Model No: | C003-01-4G |
| Certificate: | ISO CE | ||
| High Light: | 4G LTE Vehicle GPS Tracker,ACC Input Detection GPS Tracker,LBS Positioning GPS Tracking Device |
||
Protocol GT06 Vehicle GPS Tracker GPRS SMS Online Tracking Moving Alarm 4G GPS Tracker
Features
| GSM850/900/1800/1900mhz, |
| WCDMA850/900/1900/2100 Mhz |
| FDD-LTE 800/850/900/1800/2100/2600MHz |
| Wide operating input voltage range: 9-80VDC; |
| GPS / LBS real-time positioning |
| support the computer to track the car |
| mobile search vehicles |
| wechat search vehicles |
| Support SMS text query location information |
| Built-in vibration sensor |
| Able to set a specific number for SOS alarm and burglar alarm |
| SOS switch button for emergency call for help; |
| GSM: | 850/900/1800/1900 Quad band |
| GPRS: | Class12, TCP/IP |
| Working Voltage | 9-100V DC |
| Working current: | ≈22mA (12vDC) |
| Working current: | ≈12mA (24vDC) |
| GPS locating time: | Cold start≈38s(Open sky) Warm start≈32s Hot start≈2s(Open sky) |
| GPS Precision: | 10m(2D RM) |
| Working temperature: | *-20℃～+70℃ |
| Working humidity: | 20%～80%RH |
| Measurement: | 90(L)×40(W)×15(H)mm |
Protocol GT06 Vehicle GPS Tracker GPRS SMS Online Tracking Moving Alarm 4G GPS Tracker
Functions:
| GPS | functions: |
| protocol: GT06 | 1)support ACC ignition checking |
| G-sensor : BS250E | 2)support Relay for cutting off power/fuel |
| input power: 9-100V | 3)built-in GPS antenna: 18*18*4 mm |
| power IC: SL3036H | 4)built-in battery, Real time tracking |
| GSM module: MT6261 | 5)Geo-fence, over speed alarm, |
| GPS module: Ublox | 6) platform /APP supported |
Product Specification
| Frequency | North America EC25-A EC25-V:LTE FDD: B2/B4/B12 WCDMA: B2/B4/B5 LTE FDD: B4/B13 |
| Nerworks | 4G/3G/2G |
| Battery | 200mah |
| Operating Voltage | 9-100v |
| Location time | Hot start≈2s(Open sky) |
| Location accuracy | 5-10M |
| Operating temperature | -20℃～+70℃ |
| Dimension | 90*40*15mm |
| Weight | 0.05kg |
Protocol GT06 Vehicle GPS Tracker GPRS SMS Online Tracking Moving Alarm 4G GPS Tracker
Produce Description
| GSM | GPRS |
| Geo-sensor | Input power |
| ACC | Ignition checking |
| Built-in battery | Cutt off power/fuel |
| Real time tracking | Over speed alarm |
| Relay supported | Platform /APP supported |
Preparation for the installation
| 1 . Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer. |
| 2 . Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference. |
| 3 . SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder. |
| 4 . Put back the front cover and screw it up. |
| 5 . Connect the device to the 9-100Vpower supply.(the red LED constant glow) |
| 6 . Install the device in the hidden place of the car； |
Protocol GT06 Vehicle GPS Tracker GPRS SMS Online Tracking Moving Alarm 4G GPS Tracker
Installation for the Car/Motorcycle/E-bike
The GPS tracker must be installed under professional personnel.
Note:
1) Please install the device in the hidden place as followings:
2) Avoid being placed with signal radiators like reverse sensor ；
3) The device has GSM antenna and GPS antenna inside. Please ensure the receiving side of the device is face up and without metal cover.
Note:The metal cover will lessen the receiving of GPS signals.
Device wiring requirements
1 The device power supply is DC 9-100V. The red line is positive pole while the black line is negative pole.
2 The negative pole of power supply connects with ground or the metals. Please do not connect with other ground lines.
3 When finishing the power supply wire connection, please make the plug of power supply to the device
