Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor

Certification
Good quality Motorcycle GPS Tracker for sales
Good quality Motorcycle GPS Tracker for sales
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

I'm Online Chat Now

Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor

China Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor supplier
Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor supplier Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor supplier Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor supplier

Large Image :  Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor

Product Details:

Place of Origin: China
Brand Name: CARTRACKER
Certification: CE/ROHS/FCC/SGS
Model Number: CLF2-700

Payment & Shipping Terms:

Minimum Order Quantity: 10 pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 100,000pcs per month
Contact Now
Detailed Product Description
Product Name: Resistance Fuel Sensor Accuracy: 99.5%
Can Be Cut Or Not: Yes Material: Aluminum Alloy
Length: Can Be Customize Made, Normally 70cm



Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor



Performance Index:



Examination area: 100~1000mm

resolution ratio: 0.1%

Measuring accuracy:0.1%

Maximal error of measure :1mm

heat-resistant :-40~150

Diameter Φ18mm

Output signal :4~20mA,0~5V, RS485, RS232, CAN bus

Voltage supply :DC7~42V

Rated supply :0.1W

Fixed type :Screw installation M20X1.5 OR Flange mounting

Pressure range :-0.1MPa ~ 0.1 MPa

ambient temperature -40~85℃

Length, default is 700mm, 1000mm, Length can be customized and cut.



Features:

1, connect with analog input.

2, Accuracy: 99.5%

3, Material: aluminum alloy.

4, Data transition: 0-5V, 0 means empty, 5V means full.

5, Length can be customize made, normally 70cm. can be cut.





Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor



Different types output, Analog output 0-5V, RS232, 4-20MA, RS485



Capacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor MonitorCapacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor MonitorCapacitive Fuel Sensor Liquid Level Monitor High Accuracy diesel Sensor Monitor



Applicaiton:



fuel sensor



Gurantee:

12 months.
