Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device

Certification
Good quality Motorcycle GPS Tracker for sales
Good quality Motorcycle GPS Tracker for sales
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

I'm Online Chat Now

Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device

China Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device supplier
Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device supplier Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device supplier Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device supplier

Large Image :  Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device

Product Details:

Place of Origin: China
Brand Name: CAX
Certification: CE
Model Number: CA-OBD-4G

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 work days
Payment Terms: Western Union, T/T
Supply Ability: 100000 PCS Per month
Contact Now
Detailed Product Description
Model Name: Car GPS Tracker Function2: Real Time Tracking
Color: Black Weight: 30g
Size: 67mm*45mm*25mm Diagnastic: Support
Network: 4G Warranty: 2 Years,
Geo-fence: Yes Input Voltage: DC 12V/1A

Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device


 Features:





Items Specifications
Dimension 72*48*24 mm
Weight 100g
Input Voltage DC 12V/1A
Back-up Battery 150mAh/3.7V
Power Consumption 100mA
Operating Temperature -20 ° C~55 ° C
Humidity 5%~95%
Work Time 15 hours in power-saving mode and 3 hours in normal mode
LED 2 LED lights to show GPS/GSMstatus
Microphone/Speaker Internal microphone and speaker
Sensor Tremble sensor
GSM Frequency GSM 850/900/1800/1900MHz
GPS Chip Latest GPS SIRF-Star IV chipset
GPS Sensitivity -163dB
Positioning Accuracy 10 meters





1. Ruqest for OBD data by SMS
2. Mileage setting
3. Fuel tank volume setting
4. Notification of vehicle fault
5. Vehicle maintenance notification
6. Tracking via SMS or GPRS (TCP/UDP)
7. Geo-fencing control and alarm
8. Speeding alert
9. Get detail address or Google map link via SMS
10. Low battery alert
11. SOS panic button
12. Voice monitoring
13. Arm/disarm
14. ACC on alert
15. GPS blind spot alert
16. LBS tracking
17. Movement alert



1. Plug & play design with OBD-II connector, compatible with all the vehicles with OBD-II connector, supports all the CAN-BUS communication protocols;
2. It is the integration of GPS tracker + RFID car alarm + Bluetooth diagnostics;
3. Arm/disarm by SMS/phone call, or by 2.4G RFID tag automatically;
4. Check the real physical address (such as city name, street name.) directly;
5. Track by SMS/website to get the latitude, longitude, speed, direction & odometer etc.;
6. Movement alarm, Over-speed alarm, Geo-fence alarm;
7. Engine on alarm, power failure alarm, vibration alarm;
8. Anti-tamper alarm. Once the device is disconnected, it will trigger the alarm;
9. Built-in shock sensor for power saving & triggering vibration alarm;
10. Monitor the voice;
11. Supports 2.4G long-distance contactless RFID function(optional);
12. Keyless RFID car alarm function(optional);
13. Accurate odometer & speed reading directly via CAN-BUS;
14. Data logger 8Mb for offline GPS waypoint;
15. Read the vehicle error code & clear the error code ;
16. Built-in rechargeable backup battery; when the car battery is cut off or damaged, the built-in backup battery can work for emergency check, and the system will send out power failure alert immediately.
17. Two kinds of location information; user can check the GPS latitude, longitude, speed, direction. If there is no GPS signal, user could also locate the car by GSM base station code.
18. Remote diagnostics function. Transmission of the following data via blue-tooth or GPRS network:


Technical Parameters:

 1. GSM: 850/900/1800/1900 Quad band.
 2. GPRS: Class12. TCP/IP
 3. Working Voltage: DC12V
 4. Working Current: about 22mA( DC12V)
 5. GPS Locating Time: Cold start about 38s,Warm start about 32s, Hot start about 2s
 6. GPS Precision: 10m
 7. Working temperature: -20 degree to +70 degree
 8. Working humidity: 20%-80%RH
 9. Measurement: 67mm*45mm*25mm

Picture:




Power cut off alarm:



When GPS device be remove from vehicle, or power with be cut off, it will send alarm to user by SMS and system.







Over speed alarm:



Real time remote monitor driver behavior, send alarm information to manager when vehicle over speed.



Back up battery:

If GPS device be removed, it will can send alarm by back up battery and keep tracking location for about 4hours.





Geo fence alarm / drive area limit alarm:

Set up a Geo -fence for the GPS to monitor it`s movement area, the GPS will alarm when vehicle out of this area.



Audio monitoring:

You can call the GPS device and listen the vehicle inside voice when driver unknow. The GPS device not vibrate or ring



Mileage statistics:



Calculate vehicle driving mileage in a period of time.


Applications :

4S shop , car company , truck company , motorcycle company , GPS producer , large-scale shopping malls , exclusive agency , chain shops , large-scale sales , car repair shop,taxi company .


Gurantee:

1. All of our product is free to use the Tracking service server in 24 hours each day
2. All of our product there is a 2 year quanlity assurance.
3. Sample fee will not  be returned.


Product Configuration:

1. Standard configuration

  1. GPS Tracker Device
  2. User manual



Fleet management:



You can manage all vehicles on the website tracking software at same time.





History daily report:



Check the vehicle work information in whole day, the location in anytime, the speed, time, ACC condition, stop time, stop place etc.





Vehicle stop report:

Check vehicle stop how long time and stop place.





Android app:

You can real time tracking vehicle on our android app, one account can check all of your vehicles.



Plug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking DevicePlug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking DevicePlug and Play Obd II 3G GPS Vehicle Ttracker 3G Tracking Device
