Product Details:
Payment & Shipping Terms:
|
Placement: | Windshield, Instument Panel | Function: | ACC Ignition Checking |
---|---|---|---|
Certification: | CE ISO | Use: | Automotive |
Antenna: | Built-in GPS Antenna: 18*18*4 Mm | Battery: | 200mAH |
Weight: | 50g | Warranty: | 2 Years |
High Light: | Geo Fence Sensor Wcdma Gps Tracker,200mAH Wcdma Gps Tracker,TCP IP Car Gps Tracker |
Free Cost Platform/APP Geo-fence sensor C003-01-4G Model Vehicle Car 4G GPS Tracker
Parameter
Size | 90(L)×40(W)×15(H)mm |
Working temperature | -20℃~+70℃ |
Working Voltage | DC9-100V |
Weight | 50g |
Built-in Battery | 200MAH |
Hardware Specification
Location Accouracy | 10M |
GPS Chip | MT6261 |
FDD-LTE Frequency | 800/850/900/1800/2100/2600MHz |
GPS antenna | Built-in,18*18*4 mm |
GPRS | Class12 TCP/IP |
Software Specification
ACC Detection | support |
GEO-fence | support |
Cut power | support |
Vibration | support |
Movement | support |
Free Cost Platform/APP Geo-fence sensor C003-01-4G Model Vehicle Car 4G GPS Tracker
Indicators
LIGHT | Functions |
Red LED | Connect DC 9-100V power supply and will light continuously. |
The red LED is the power signal, | |
It is always on when the external DC is connected. | |
Blue LED | It is he GSM signal indicator. |
It is always on when there is no GSM; | |
It flashes when GSM is normal; | |
It flashes quickly when transmitting data. | |
Yellow LED | It is the GPS signal indicator: |
It is always on when there is no positioning; | |
It flashes after positioning. |
Main Features :
1. Quick and Easy installation: Through clever design and innovation, Mini GPS couled be hided in panel. |
2. Real Time Tracking |
3. Smart Geo fencing: Define a safe zone in the APP/WEB and you are ready to receive an alarm |
4. Location history:supports up to 180 days historical route track; |
5. APP+WEB monitoring service: Just open up the APP/WEB and watch its movements in real time. |
Free Cost Platform/APP Geo-fence sensor C003-01-4G Model Vehicle Car 4G GPS Tracker
4G Bands
Europe / Middle East / Africa / South Korea / Thailand
EC25-E:
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
North America
EC25-A:
LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
EC25-V:
LTE FDD: B4/B13
Australia/New Zealand/Taiwan/Brazil:
EC25-AU:
LTE FDD: B1/B2*/B3/B4/B5/B7/B8/B28
LTE TDD: B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
EC25-AUT:
LTE FDD: B1/B3/B5/B7/B28
WCDMA: B1/B5
EC25-AUTL:
LTE FDD: B3/87/828
Japan EC25-J
LTE FDD: B1/B3/B8/B18/B19/B26
LTE TDD: B41
WCDMA: B1/B6/B8/B19
Free Cost Platform/APP Geo-fence sensor C003-01-4G Model Vehicle Car 4G GPS Tracker
FAQ
Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;
Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;
Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.
Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;
Q5: How about your platform cost?
Re: Free for lifetime;
