Product Details:
Payment & Shipping Terms:
|
Connection: | 3G/4G Sim Card, 2G Sim Card | Certification: | CE ISO9000 |
---|---|---|---|
Use: | Automotive | Material: | Engineering Plastic |
Packing: | Carton/wooden Box | Battery: | 200mAH |
Combination: | 4G GPS Tracking | Warranty: | 2 Years |
High Light: | Geo Fence 4G GPS Tracker,FCC 4G GPS Tracker,GPS LBS Diagnostic Code Reader |
GPS Mini Smart Electronic fence Tracker 2G 3G 4G Tracking System 4G GPS Tracker
Model | GT06 |
Features | Vehicle malfunction diagnostics |
Device Dimension | 90mm(L)*40mm(W)*15mm(H) |
Weight | 50g |
Quad Band | 850/1900/900/1800MHz |
GPS Accuracy | 5-10m |
Voltage Input | 9-100v |
Hot Start<2S(Open Sky) | |
Positioning Time | Warm Start<15S |
Cold Start<32S(Open Sky) | |
Tracking Sensitivity | -162dBm |
GPS chip | MTK6261 |
GSM/GPS Antenna | Built-in Design |
Product feature
1.Precise positioning with accouracy of 5 meters
2.GPS+LBS positionging
3.Functions:ACC Detection,remote power/circuit,DC detection,overspeed alarm,voice intercom,Geo-fence,etc…
4.Industrial design,working voltage,input:9V-100V
GPS Mini Smart Electronic fence Tracker 2G 3G 4G Tracking System 4G GPS Tracker
Dvice parameter
Electronic Character: | |
Power Supply | built-in battery |
Work Voltage | DC9-100V |
Work Current | ≈22mA (12vDC) |
Work Current | ≈12mA (24vDC) |
Battery Capacity | 200mah |
Environment Character: | |
Work Temp: | -20℃~+70℃ |
Storage Temp: | -30℃~+80℃ |
Work Humidity: | 20%~80%RH |
Communication Character | |
Module Brand/Chip Module:MT6261 | |
Band:B1/B3/B8B34/B38/B390/B40/B41/BC0 | |
SIM Card: | Standard SIM card |
Aerial: | Internal |
GPS/BD Positioning Character: | |
Cold start | 38s(Open sky) |
Warm start | 32s(Open sky) |
Hot start | 2s(Open sky) |
Shape | |
Dimension | 90mm*40mm*15mm |
Weight | 50g |
GPS Mini Smart Electronic fence Tracker 2G 3G 4G Tracking System 4G GPS Tracker
4G bands in different countries:
Europe / Middle East / Africa / South Korea / Thailand
EC25-E:
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
North America
EC25-A:
LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
EC25-V:
LTE FDD: B4/B13
Australia/New Zealand/Taiwan/Brazil:
EC25-AU:
LTE FDD: B1/B2*/B3/B4/B5/B7/B8/B28
LTE TDD: B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
EC25-AUT:
LTE FDD: B1/B3/B5/B7/B28
WCDMA: B1/B5
EC25-AUTL:
LTE FDD: B3/87/828
GPS Mini Smart Electronic fence Tracker 2G 3G 4G Tracking System 4G GPS Tracker
Remote monitoring
Specific number can monitor GPS device SIM card number
SMS:88
Note: Need to set the owner number and SOS specific number at first
SMS Text Query Location Information
1 When you need to query the terminal device location information, you can text
messages send to the SIM card on the device, the device will reply the last location.
SMS: 123
2 Owner number call the device reply location information, ring twice then hang up.
3 Google Link SMS: g1234
Speed Alarm Settings
Overspeed alarm SMS Speed Limit:
speed123456 080
Setting the speed limit of 80 km / h
1 Turn off speed alarm SMS (default)
speed123456 000
Re: speed ok
2 Turn on speed alarm SMS
speed123456 080
Re: speed ok
Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;
Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;
Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.
Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;
Q5: How about your platform cost?
Re: Free for lifetime;
