High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking

I'm Online Chat Now
Certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking
High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking

Large Image :  High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking Get Best Price

Product Details:
Place of Origin: China
Brand Name: Cartracker
Certification: CE,ISO9000
Model Number: C003-01-4G
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Packed in carton firstly
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or western Union or paypal
Supply Ability: 10,000pcs per month
Detailed Product Description
Model Number: C003-01-4G GPS TRACKER Dimensions: 90*40*15MM
Battery: Built-in 200mAh Communication Protocol: TCP / IP
4G Frequency: FDD LTE 800/850/900/1800/2100/2600MHZ Certificate: ISO CE
Working Voltage: DC9-100V Working Humidity: 20%-80%RH
High Light:

4G LTE Vehicle GPS Tracker

,

ACC Input Detection GPS Tracker

,

LBS Positioning GPS Tracking Device

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking



Parameter

GSM two-way 850/900/1800/1900 MHz
GPS positioning GPS sensitivity: -162dBm
GPS positioning accuracy: 5 meters (under open conditions)
Speed ​​accuracy: 0.1 m/s
Cold start time: <38 seconds
Warm start time: <32 seconds
Hot start time: <2 seconds
Base station positioning Support base station positioning, positioning accuracy: 10~200 meters
Working current Average current ≈22mA (12vDC) maximum current <100mA (12VDC)
Operating temperature -20~+70℃
Material Engineering plastics
Weight 50G
Network 4G LTE/3G WCDMA /2G GSM
Dim. 90*40*15mm
Storage Temp. -40°C to +85°C
Accuracy 5-20m
Operation Temp. -20°C to +55°C
Humidity 20%--80% non-condensing
Working Voltage 9-100V
CPU MTK6261



Produce Description

GSM GPRS
Geo-sensor Input power
ACC Ignition checking
Built-in battery Cutt off power/fuel
Real time tracking Over speed alarm
Relay supported Platform /APP supported



High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking 0



High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking



Product Specification

Frequency North America EC25-A
EC25-V:LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
LTE FDD: B4/B13
Nerworks 4G/3G/2G
Battery 200mah
Operating Voltage 9-100v
Location time Hot start≈2s(Open sky)
Location accuracy 5-10M
Operating temperature -20℃~+70℃
Dimension 90*40*15mm
Weight 0.05kg





Produce Description

GSM GPRS
Geo-sensor Input power
ACC Ignition checking
Built-in battery Cutt off power/fuel
Real time tracking Over speed alarm
Relay supported Platform /APP supported

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking 1

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking

Functions

Platform
up to 180 days historical route track electronic fence, out of the regional alarm
deviate planning route alarm serious collision warning (optional);
rollover warning (optional); overspeed alarm
report output free to use



1. Real-Time Positioning:

C003-01-4G GPS Tracker Device will get the real-time position message and upload all status to the server system.
And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. Speed
GPS Time, direction, and so on.



2. Vibration alarm:

After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.



3. Power-off alarm:

If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.



4. Remote Car Lock:

If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.



High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking 2

High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking

Main components

GPS                              Functions:

protocol: GT06             1)support ACC ignition checking ,
G-sensor : BS250E      2)support Relay for cutting off power/fuel
input power: 9-100V     3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H      4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm,

GPS module: Ublox      6)platform /APP supported



Device status indicators

1 Connect DC 9-100V power supply and the red LED will light continuously.

   The red LED is the power signal,

    it is always on when the external DC is connected.



2 The blue LED is the GSM signal indicator.

   It is always on when there is no GSM

   it flashes when GSM is normal;

   it flashes quickly when transmitting data.



3 The yellow LED is the GPS signal indicator:

   it is always on when there is no positioning;

   it flashes after positioning.
