TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles

I'm Online Chat Now
Certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles

TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles
TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles

Large Image :  TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles Get Best Price

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Caxtrack
Certification: CE/ROHS/SGS/FCC
Model Number: CA-TK003
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Neutral or Customized
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or Western Union or PayPal
Supply Ability: 1,000,000pcs per month
Detailed Product Description
Warranty: 1 Year Function: Real Time Tracking
Position Accuracy: 5 Meters Working Voltage: DC9-100V
GPRS: Class 12 TCP IP GPS Module: MT6261
Protocol: Concox GT06 Color: Black
Size: Mini
High Light:

Concox GT06 Motorcycles GPS Tracker

,

MT6261 Motorcycles GPS Tracker

,

5m Real Time Gps Tracker

TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles



Main components: (V1.0)



GPS functions:

protocol: GT06 1)support ACC ignition checking ,
G-sensor : BS250E 2)support Relay for cutting off power/fuel
input power: 9-100V 3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H 4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm, GPS module: Ublox 6) platform /APP supported



Product Parameters

Device Name Vehicle GPS Tracker
Model TK003
Features Multiple functions
Device Dimension 83mm(L)*40mm(W)*14mm(H)
Box Dimension 130mm(L)*90mm(W)*30mm(H)
Device Weight 38g
Package Weight 200g
Quad-Band 850/1900/900/1800MHz
GPS Accuracy 5-10m
Voltage Input 9-90v
Back-up Battery 250mAh
Positioning Time Hot Start<2S(Open Sky)
Warm Start<15S
Cold Start<32S(Open Sky)
GPS Sensitivity -144dBm
Tracking Sensitivity -160dBm
Operating Temperature -25℃—75℃
GPS chip MTK
GSM/GPS Antenna Built-in Design




Multi-Mode Positioning: BD GPS LBS











Device status indicators



4.1 Connect DC 9-100V power supply and the red LED will light continuously.

The red LED is the power signal,

it is always on when the external DC is connected.



4.2 The blue LED is the GSM signal indicator.

It is always on when there is no GSM;

it flashes when GSM is normal;

it flashes quickly when transmitting data.



4.3 The yellow LED is the GPS signal indicator:

it is always on when there is no positioning;

it flashes after positioning.



TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles

Functions

Real-time Tracking update position every 10 seconds with continuous tracking.
Fast Positioning provide a timely positioning service after installing it.
Trace Playback check the history trace of your vehicle to help you find useful information.
Mileage Report can help you to know how far you drive.
Over-speed Alarm when your speed is over what you set, it will send an alarm to remind you to keep safe.
Geo-fence Alarm users can set a range of geofence on the map with a circle, polygon, or customize the shape, and it will alarm when the device gets in or out of preset range via APP or SMS.
Remotely Cut-off Petrol/Electricity Remote control vehicle engine via the platform, app, or SMS to avoid someone driving the vehicle illegally.
SOS Emergency Call makes an emergency call when in danger.
Remotely Voice Monitoring remotely hear the sound around the vehicle
Platform/APP/SMS Checking various methods like platform, app, SMS to check asset status.


TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles 0

TK003 Waterproof Boat Tracking Key Size Smart GPS Device Cars Motorcycles Vehicles







GPS Tracker Main Functions:



1. Real-Time Positioning:



TK003 GPS Tracker Device will get the real-time position message and upload all status to the server system.



And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. speed



GPS Time, direction, and so on.



2. Vibration alarm:



After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.



3.  Power-off alarm:



If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.



4.  Remote Car Lock



If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.



Terminal connection:



male switch, Female switch

Red(positive) Black (Negative)



1. red wire connect positive(+),black wire connect negative(-)

2. power input connector to power positive and negative connectors( make sure to connect the right connector)
