Real Time Positioning Car Gps Tracker With Cheap Cost Free App

I'm Online Chat Now
Certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
China SHENZHEN YITUOWULIAN SYSTEM CO.,LTD certification
We are very satisfied with your CA-V1 and CA-V1, CA-V6W for professional customers, CA-V6W is a very good product on the motorcycle,thanks!

—— Touya_ra

now we already used your company CA-V6 more than 2000Pcs, thanks for your company best support, we will expend this business in all of the Kenya

—— Nancy Saruni

your device CA-V1 is very good for our customer project, it is so proffesional , we can use in refrigerator car which can test the temperature ,thanks

—— Rajesmay

Real Time Positioning Car Gps Tracker With Cheap Cost Free App

Real Time Positioning Car Gps Tracker With Cheap Cost Free App
Real Time Positioning Car Gps Tracker With Cheap Cost Free App Real Time Positioning Car Gps Tracker With Cheap Cost Free App Real Time Positioning Car Gps Tracker With Cheap Cost Free App

Large Image :  Real Time Positioning Car Gps Tracker With Cheap Cost Free App Get Best Price

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Caxtrack
Certification: CE/ROHS/SGS/FCC
Model Number: CA-TK003
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Neutral or Customized
Delivery Time: 1-10 working days after received your payment
Payment Terms: T/T or Western Union or PayPal
Supply Ability: 1,000,000pcs per month
Detailed Product Description
Warranty: 12 Month Function: Real Time Tracking
Position Accuracy: 5 Meters Working Voltage: DC9-100V
GPRS: Class 12 TCP IP GPS Module: MT6261
Protocol: GT06 Color: Black
Size: Mini Gps Accuracy: 5~15 M,
High Light:

MT6261 Real Time Gps Tracker

,

1W Real Time Gps Tracker

,

GT06 Protocol Gps Car Tracker



Real-Time Positioning Car Gps Tracker With Cheap Cost Free App



Main components: (V1.0)



GPS functions:

protocol: GT06             1)support ACC ignition checking ,
G-sensor : BS250E      2)support Relay for cutting off power/fuel
input power: 9-100V     3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H      4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm, GPS module: Ublox 6) platform /APP supported



GPS Tracker Parameters:



Working Voltage: DC9-100V or 12-40V, optional.
GSM Chip: MT6261
GPS Chip: AT6558R
MPS 9486
Working temperature: ‘-20 ℃ to +70 ℃
Storage temperature: ’-40 ℃ to +80 ℃
Working Humidity: 5% to 90%
Power consumption: Average power consumption<1W, power-saving status<2mW
GPS Tracker size: 76mm*27mm*15mm
Packing size: 80mm*125mm*40mm
Interface: Power input, ACC input detection, cut off fuel circuit.
Communication band: GSM/GPRS 850MHz 900MHz 1800MHz 1900MHz
Weight:
38g



Multi-Mode Positioning: BD GPS LBS



Key Features:

-Change Password

-Authorization

-Single Locating

-Auto track continuously

-GPS drift suppression

-Absolute street address by SMS

-Location-based service (LBS)

-Forward the third parties’ message

-Charges Inquiry

-Alarm Function

-Low battery alarm

-External Power off the alarm (Suitable for B, C, and D model)

-GPS blind Spot alert

-SOS

-Geo-fence

-Multi-area management

-Movement alarm

-Over speed alarm

-ACC working alarm (Option, for model B, C, D)

-Fuel alarm (Option, for model C, D)

-Cut off the Oil and Power System (Option, for model C, D)

-Function of Remote Controller (Option, for model D ONLY)

-Arm

-Silent Mode

-DISARM

-Alarms under Arm State

-Door alarm (Option for model C and D)

-ACC alarm (Optional for model B, C, D )

-Shock Sensor alarm

-Check the Vehicle State

-Reset Hardware

-Check IMEI

-Set up Terminal (local) Time

-TCP / UDP Switch

-Configure parameters by USB

-GPRS setting

-Setting up APN

-GPRS User ID and password Setup

-IP and port setup

-Less GPRS traffic

-Modes Switch between “SMS” and “GPRS”

-Set up monitor center number.





Device status indicators



4.1 Connect DC 9-100V power supply and the red LED will light continuously.

The red LED is the power signal,

it is always on when the external DC is connected.



4.2 The blue LED is the GSM signal indicator.

It is always on when there is no GSM;

it flashes when GSM is normal;

it flashes quickly when transmitting data.



4.3 The yellow LED is the GPS signal indicator:

it is always on when there is no positioning;

it flashes after positioning.



Real-Time Positioning Car Gps Tracker With Cheap Cost Free App



GPS Tracker Applications And Where you install it.



Real Time Positioning Car Gps Tracker With Cheap Cost Free App 0

Real Time Positioning Car Gps Tracker With Cheap Cost Free App 1







GPS Tracker Main Functions:



1. Real-Time Positioning:



TK003 GPS Tracker Device will get the real-time position message and upload all status to the server system.



And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. speed



GPS Time, direction, and so on.



2. Vibration alarm:



After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.



3.  Power-off alarm:



If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.



4.  Remote Car Lock



If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.



5.  SOS Alarm



Users can press the SOS button on GPS Tracker in emergency situations. GPS Tracker will send an alarm message to manage the system and

Call police simultaneously.



Terminal connection:



male switch, Female switch

Red(positive) Black (Negative)



1. red wire connect positive(+),black wire connect negative(-)

2. power input connector to power positive and negative connectors( make sure to connect the right connector)



set server IP or Domain name

1. Set server Domain name: SERVER,1, domain name, port,0#

2. Set Server IP:

SERVER,0,IP, Port,0#

The last bit 0 stands for TCP



Real-Time Positioning Car Gps Tracker With Cheap Cost Free App
